XC6SLX16-3CSG324C The Advanced Micro Devices XC6SLX16-3CSG324C is an FPGA with 14,579 logic elements and 232 I/O pins. It features a surface mount package and operates at 1.14V to 1.26V.
Mfr Part #:

XC6SLX16-3CSG324C

Available from 2 distributors
Mfr Name: Advanced Micro Devices
Advanced Micro Devices
The Advanced Micro Devices XC6SLX16-3CSG324C is an FPGA with 14,579 logic elements and 232 I/O pins. It features a surface mount package and operates at 1.14V to 1.26V.
✓ Total Stock: 10,136 pcs
$ Price Range: $21.20

XC6SLX16-3CSG324C Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
8,745 pcs
On Request
8745 pcs On Request 1 On Request On Request On Request On Request On Request
Romaks Technologies ✓
Non-Authorised Inventory information
1,391 pcs
On Request
1391 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

XC6SLX16-3CSG324C Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Spacing
Mounting Type
Number of I
Number of LABs
Number of Logic Elements
Operating Temperature
Supplier Device Package
Supplier Package
Tape & Reel
Total RAM Bits
Voltage
View Similar Products (0)

XC6SLX16-3CSG324C Description

Short technical summary and product information.

The Advanced Micro Devices XC6SLX16-3CSG324C is a Field Programmable Gate Array (FPGA) designed for embedded applications. It offers 14,579 logic elements and 1,139 logic array blocks, with a total of 589,824 RAM bits.



This FPGA provides 232 I/O pins and operates within a voltage range of 1.14V to 1.26V. The operating temperature is specified as 0°C to 85°C (TJ).



Packaged in a 324-LFBGA, CSPBGA format, this component is designed for surface mounting. Its supplier package is listed as 324-CSPBGA (15x15).



Compliance information indicates RoHS3 compliance, MSL 1 Unlimited, and REACH Unaffected status. However, these compliance details are unverified.

XC6SLX16-3CSG324C Quick Information

Product Type: FPGA
Series: Spartan-6
Canonical Name: XC6SLX16-3CSG324C FPGA
Subcategory: Field Programmable Gate Array

XC6SLX16-3CSG324C Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

XC6SLX16-3CSG324C Estimated Pricing

Qty Low High
1+ $21.20 $21.20

Estimated market price range - modelled values for guidance only, not live distributor offers.

XC6SLX16-3CSG324C Features

  • High logic element count of 14,579
  • 232 I/O pins for versatile connectivity
  • Operates at 1.14V to 1.26V
  • Surface mount 324-LFBGA package
  • Operates within 0°C to 85°C temperature range

XC6SLX16-3CSG324C Applications

  • Suitable for embedded FPGA applications
  • Ideal for high-density logic designs
  • Used in complex digital systems
  • Designed for surface-mount PCB integration

XC6SLX16-3CSG324C FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating temperature range for the XC6SLX16-3CSG324C?

The operating temperature range is 0°C to 85°C (TJ).

How many I/O pins does the XC6SLX16-3CSG324C FPGA have?

It has 232 I/O pins.

What is the operating voltage for this FPGA?

The operating voltage is between 1.14V and 1.26V.

What package type is the XC6SLX16-3CSG324C supplied in?

It is supplied in a 324-LFBGA, CSPBGA package.

What is the Moisture Sensitivity Level (MSL) for this component?

The MSL is 1 Unlimited.
