| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Clock Frequency | |
| Industrial Grade | |
| Lead Style | |
| Mounting Type | |
| SVHC Present | |
| Storage Temperature |
The Xilinx XC3S50-4VQ100I is a Field Programmable Gate Array (FPGA) designed for various electronic applications. This component features 192 CLBs (Configurable Logic Blocks) and an equivalent gate count of 50000, providing significant logic capacity.
With a maximum clock frequency of 630 MHz, the XC3S50-4VQ100I is suitable for high-speed processing tasks. It operates within a supply voltage range of 1.14 V to 1.26 V, with a nominal voltage of 1.2 V. The device is housed in a 100-pin VQFP (Very Thin Quad Flat Package) with a square shape and gull wing terminal form, designed for surface mounting.
The terminal pitch is 0.5000 mm, and the terminals are finished with Tin Lead. The package body material is plastic/epoxy. This FPGA is classified as a Field Programmable Gate Array, offering flexibility in hardware design and implementation.
| Qty | Low | High |
|---|---|---|
| 1+ | $22.15 | $22.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum clock frequency for the XC3S50-4VQ100I is 630 MHz.
The supply voltage range for the XC3S50-4VQ100I is 1.14 V to 1.26 V, with a nominal voltage of 1.2 V.
The XC3S50-4VQ100I has 192 CLBs (logic elements) and 50000 equivalent gates.
The XC3S50-4VQ100I is in a 100-pin VQFP (VQ100) square package for surface mounting.
The terminal pitch is 0.5 mm, and the terminal form is gull wing.
