WTB14PR7J AirBorn WTB14PR7J is a 14 position, 2.54mm pitch right angle plug connector with male pins. It features gold contacts, through hole mounting, and solder termination.
Mfr Part #:

WTB14PR7J

Available from 1 distributors
Mfr Name: AirBorn
AirBorn
AirBorn WTB14PR7J is a 14 position, 2.54mm pitch right angle plug connector with male pins. It features gold contacts, through hole mounting, and solder termination.
✓ Total Stock: 5 pcs
$ Price Range: $30.43 - $52.47

WTB14PR7J Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
5 pcs
On Request
5 pcs On Request 1 On Request On Request 1423 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

WTB14PR7J Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Failure Rate
Features
Mounting Type
Number of Columns
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Termination
View Similar Products (0)

WTB14PR7J Description

Short technical summary and product information.

The AirBorn WTB14PR7J is a 14 position, right angle plug connector from the WTB series. It features 2 rows of 7 columns with male pins on a 2.54mm (0.100") pitch. The connector uses through hole mounting with solder termination, and the contacts are gold-plated for reliable electrical performance. Additional features include a mating guide and mounting flange to aid in alignment and secure attachment. The contact termination style is PR7, which is a pin, right angle, dip solder type with .109" x .025" diameter tails. This connector is designed for use in rectangular PCB connector applications, typically in backplane or internal wiring scenarios.

WTB14PR7J Quick Information

Product Type: Rectangular PCB Connector
Series: WTB
Canonical Name: AirBorn WTB Series 14 Position 2.54mm Pitch Right Angle Plug, Male Pins, Through Hole, Solder Termination
Subcategory: Rectangular PCB Connector

WTB14PR7J Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

WTB14PR7J Estimated Pricing

Qty Low High
1+ $52.47 $52.47
10+ $43.70 $43.70
25+ $43.48 $43.48
50+ $37.23 $37.23
250+ $30.43 $30.43

Estimated market price range - modelled values for guidance only, not live distributor offers.

WTB14PR7J Features

  • 14 position, 2-row, 7-column configuration.
  • 2.54mm pitch for compact designs.
  • Right angle through hole mounting.
  • Gold-plated male pins.
  • Includes mating guide and mounting flange.

WTB14PR7J Applications

  • Used in backplane interconnect systems
  • Suitable for PCB-to-cable connections
  • Applied in military and aerospace electronics
  • Ideal for high-density signal transmission
  • Used in industrial control equipment

WTB14PR7J FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the WTB14PR7J have?

14 positions.

What is the pitch of this connector?

2.54mm (0.100").

What is the mounting type?

Through Hole, Right Angle.

What type of connector is this?

Plug, Male Pins.

What is the contact finish?

Gold.

What features does this connector have?

Mating Guide and Mounting Flange.

What is the termination style?

Solder.
