WRT20FWX-O The ETA WRT20FWX-O is a 20W AC-DC dual output converter featuring a universal input and chassis mount. It provides +5VDC at 2A and -5VDC at 1A outputs.
Mfr Part #:

WRT20FWX-O

Mfr Name: ETA
ETA
The ETA WRT20FWX-O is a 20W AC-DC dual output converter featuring a universal input and chassis mount. It provides +5VDC at 2A and -5VDC at 1A outputs.
Stock on Request

WRT20FWX-O Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Features
Height
Length
Mounting Type
Number of Outputs
Operating Temperature
Power (Watts)
Storage Temperature
Type
Voltage
Weight
Width
View Similar Products (0)

WRT20FWX-O Description

Short technical summary and product information.

The ETA WRT20FWX-O is a 20-watt AC-DC power supply unit designed for dual output applications. It offers a primary output of +5VDC at 2A and a secondary output of -5VDC at 1A. This converter features a universal input voltage range of 100-240 VAC (85-264 VAC) and operates across a wide frequency range of 47-440 Hz.



Designed for reliability, the WRT20FWX-O has an efficiency of 74% typical and includes protections such as over-voltage and over-current. Its operating temperature range is -10°C to 70°C, making it suitable for various environmental conditions. The unit is enclosed and designed for chassis mounting, with dimensions of 195.0mm x 55.0mm x 27.0mm.



Key electrical specifications include a line regulation of 25mV max for the +5V output and 75mV max for the -5V output, with load regulation figures of 50mV max and 150mV max respectively. Ripple and noise are kept to 80mVp-p and 120mVp-p for the respective outputs. Isolation ratings are 3000 VAC for input-output, 2000 VAC for input-F.G., and 500 VAC for output-F.G.



This AC-DC converter is certified for CE and FCC standards, complying with IEC 60950-1 safety standards and EN55022-A for RF voltage. It comes with a 2-year warranty.

WRT20FWX-O Quick Information

Product Type: AC DC Converter
Canonical Name: ETA WRT20FWX-O AC-DC Dual Output Converter
Subcategory: AC-DC Converters

WRT20FWX-O Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

WRT20FWX-O Features

  • Dual output AC-DC converter, 20W total power.
  • Universal input voltage range (100-240 VAC).
  • Chassis mountable enclosed unit.
  • Wide operating temperature range (-10°C to 70°C).
  • CE and FCC certified for safety and emissions.

WRT20FWX-O Applications

  • Powers operational amplifier bias networks.
  • Supplies symmetric rails for data acquisition.
  • Drives industrial control panel logic circuits.
  • Supports telecommunications interface modules effectively.
  • Feeds precision measurement instrumentation front ends.

WRT20FWX-O FAQs

6 frequently asked questions generated from this part’s specifications.
What are the output voltage and current ratings?

The WRT20FWX-O provides a +5VDC output at 2A maximum and a -5VDC output at 1A maximum.

How is this power supply mounted?

The unit utilizes an enclosed chassis mount configuration with dimensions of 195.0mm x 55.0mm x 27.0mm.

What is the operating temperature range?

The converter operates reliably between -10°C and 70°C, with storage capabilities extending from -20°C to 75°C.

What isolation voltage does this converter provide?

It offers 3000VAC isolation between input and output, 2000VAC between input and frame ground, and 500VAC between output and frame ground.

Does this model include overcurrent protection?

Yes, it features automatic recovery overcurrent protection that activates at 105% of the rated current.

What certifications does the WRT20FWX-O hold?

The device is certified to CE, FCC, and CB standards under IEC 60950-1 safety regulations.
