| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Industrial Grade | |
| Input Voltage | |
| Isolation | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Weight |
The ETA WRT04X-O is an enclosed AC-DC converter designed for ITE (Commercial) applications. It provides a universal input voltage range of 100-240 VAC and delivers a total power of 30W.
This triple output model offers specific voltage and current ratings: +5VDC at 3A, +15VDC at 0.2A, and -15VDC at 0.2A. It features a high efficiency of 71% and operates within a temperature range of -10°C to 70°C. The unit is designed for chassis mounting.
Key electrical protections include over-current and over-voltage protection. The converter meets safety standards such as IEC 60950-1 and complies with EN55022-A for conducted emissions. Its dimensions are 120.0mm x 81.2mm x 31.5mm, with a weight of 290g. The product comes with a 2-year warranty.
The input voltage range is 100-240 VAC (85-264 VAC or 125-370 VDC), 50/60 Hz.
The outputs are +5VDC at 3A, +15VDC at 0.2A, and -15VDC at 0.2A.
The operating temperature range is -10°C to 70°C with derating.
The mounting type is chassis mount and the package is enclosed.
It complies with IEC 60950-1 safety standard.
Over current protection at 105% of rated current and over voltage protection at 115-120% of rating, both with automatic recovery.
The efficiency is 71%.
