| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Form | |
| Input Connector | |
| Input Type | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Voltage |
This Inventus Power WP1112-760 is an AC/DC wall mount adapter designed for ITE (Commercial) applications. It delivers a stable 12V output with a maximum current of 800mA, providing a total power of 9.6W.
The adapter features a NEMA 1-15P input connector suitable for North American outlets and a standard 2.5mm inner diameter by 5.5mm outer diameter barrel plug output with a positive center polarity. Its form factor is a Class II wall mount, designed for convenient integration into various systems.
Operating within a temperature range of 0°C to 40°C, this adapter has an efficiency rating of 75%. It is CE approved, indicating compliance with European safety standards. The RoHS status is RoHS3 Compliant, and it has a Moisture Sensitivity Level (MSL) of 1 Unlimited, indicating it is not sensitive to moisture under normal conditions.
The output voltage is 12V.
The operating temperature range is 0°C to 40°C.
It is a wall mount (Class II) adapter.
The output connector is a barrel plug with 2.5mm inner diameter and 5.5mm outer diameter.
The input connector is NEMA 1-15P fixed blade.
The polarity is positive center.
Yes, the adapter is CE approved.
