| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,327 pcs
|
6327 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
6,318 pcs
|
6318 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Temperature Range | |
| Power Rating | |
| Resistance | |
| SVHC Present | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Working Voltage |
The Walsin Technology WF08P6800FTL is a surface mount chip resistor from the WF06P Series. It features a resistance value of 680 Ohms with a tight tolerance of ±1%. This resistor is rated for a power dissipation of 250mW and a continuous working voltage of 150V.
Constructed with a thick film element on a high-grade ceramic body, the WF08P series offers high reliability, precision, and stability. It operates within a temperature range of -55°C to 155°C. The 0805 (2012 Metric) case size makes it suitable for applications where space is a consideration.
This component is suitable for use in high accuracy DC power supplies, digital multimeters, telecommunications, computers, medical, and military equipment. It meets JIS C 5201-1:1998 / IEC 60068-2-58:2004 standards. The product is RoHS3 compliant and has an MSL of 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance is 680 Ohms.
Tolerance is ±1%.
The power rating is 250mW.
The temperature coefficient is ±100ppm/°C.
The package is 0805 (2012 Metric).
The operating temperature range is -55°C to 155°C.
The maximum working voltage is 150V.
