The CUI Inc. VSKM-S5-15U is an enclosed AC/DC converter designed for various applications, including medical use. It delivers 5W of power with a single output of 15VDC at 0.33A.
The converter accepts a wide input voltage range of 85 ~ 264 VAC or 110 ~ 370 VDC, featuring universal input capabilities and 76% efficiency. It is designed for through-hole mounting and comes in a 4-DIP Module package.
Key specifications include an operating temperature range of -25°C to 70°C with derating. The product is approved by CE, cULus, EN, and IEC, and complies with standard 60601-1. It is also RoHS3 compliant and has an MSL rating of 1.
Dimensions are 50.8mm x 25.4mm x 15.7mm. This part is discontinued, and inquiries should be directed to the sales team.
85 to 264 VAC or 110 to 370 VDC.
4-DIP Module with through-hole mounting.
-25°C to 70°C with derating.
15 VDC.
0.33 A.
5 W.
CE, cULus, EN, IEC 60601-1.
