| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The CUI Inc. VSK-S10-12UA is a 10W AC-DC converter designed for ITE (Commercial) applications. It provides a single 12VDC output at 0.9A, with a universal input voltage range of 85 to 264 VAC. The converter has an efficiency of 76% and operates within a temperature range of -25°C to 70°C with derating.
This AC-DC converter is housed in an enclosed 4-DIP Module package and utilizes through-hole mounting. It meets safety approvals including CE, cURus, EN, and UL standards, and complies with standard 60950-1. The unit is RoHS3 compliant and has an MSL rating of 1 Unlimited.
This part has been discontinued by the manufacturer. Recommended replacements are available, such as the PSK-10B-S12.
The output voltage is 12 VDC.
The output current is 0.9 A.
The input voltage range is 85 ~ 264 VAC.
The operating temperature range is -25°C to 70°C (With Derating).
It is mounted using the Through Hole method.
The package type is 4-DIP Module.
