| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The CUI Inc. VSK-S1-15U is a board-mount AC/DC converter with a power rating of 1 Watt and an output voltage of 15VDC. It accepts a wide input voltage range of 85 to 305 VAC, making it suitable for various global power applications. This converter features a single output and a current capability of 67mA.
Designed for ease of integration, the VSK-S1-15U utilizes a through-hole mounting type and comes in an encapsulated package. Its dimensions are 33.7mm in length, 22.2mm in width, and 18.0mm in height. The operating temperature range is -25°C to 70°C with derating.
This AC/DC converter is approved by CE, cURus, EN, and UL, and complies with standards such as 55024 and 55032 Class A. It is suitable for ITE (Commercial) applications and offers an efficiency of 74%. The product is RoHS3 compliant and has an MSL rating of 1.
85 to 305 VAC.
15 VDC at 0.067 A.
1 W.
74%.
-25°C to 70°C (with derating).
4-DIP Module, Through Hole, Encapsulated.
CE, cURus, EN, UL.
