| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
82 pcs
|
82 pcs | On Request | 1 | On Request | On Request | 24+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Dimensions | |
| Efficiency | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Power | |
| Protection Features |
The MORNSUN VRA_YMD-6WR3 series, including the VRA2415YMD-6WR3, are 6W isolated DC-DC converters designed for 1x1 inch applications. They provide a wide 2:1 input voltage range and regulated dual or single outputs, with the VRA2415YMD-6WR3 specifically offering +/-15V outputs.
Key electrical specifications include a high efficiency of up to 88% and an I/O test isolation voltage of 1500 VDC. The converters are equipped with input under-voltage protection, output short-circuit, over-current, and over-voltage protection, ensuring reliable operation.
These converters operate within an ambient temperature range of -40℃ to +85℃ and meet CISPR32/EN55032 CLASS A EMI standards without external components. They are suitable for applications in medical care, industrial control, electric power, instruments, and communication fields.
The VRA2415YMD-6WR3 comes in a DIP5 package and has a standard package quantity of 10 units. Its dimensions are 25.4 x 25.4 x 11.7 mm.
The VRA2415YMD-6WR3 provides a regulated dual output of +15 VDC and -15 VDC.
The VRA2415YMD-6WR3 has a nominal input voltage range of 18-36 VDC.
The maximum output current for each output channel of the VRA2415YMD-6WR3 is 200 mA.
The efficiency of the VRA2415YMD-6WR3 is typically 81-83% at nominal input voltage and rated output load.
The I/O test isolation voltage for the VRA2415YMD-6WR3 is 1500 VDC.
The operating ambient temperature range for this converter is -40℃ to +85℃.
Yes, it meets CISPR32/EN55032 CLASS A EMI standards without external components.
