| Category | |
| Manufacturer Name | |
| Efficiency | |
| Input Frequency | |
| Input Voltage | |
| Length | |
| Mounting Style | |
| Number of Outputs | |
| Output Power | |
| Width |
The Vicor VP-D2927817 is an autoranging VIPAC power system, also known as VCAD:VP-D2927817. This enclosed AC DC converter delivers an output power of 300W and is designed for industrial applications.
Key electrical specifications include a wide input voltage range of 90 VAC to 132 VAC and 180 VAC to 264 VAC, with an input frequency of 50 Hz/60 Hz. The unit provides regulated load output and features an isolation voltage of 3 kV. Efficiency ratings range from 70% to 80%.
Mechanically, the VP-D2927817 has a chassis mounting style, measuring 80 mm in width and 172.7 mm in length. It holds approvals such as CE, cTUVus, EN60950-1, and UL60950-1, indicating compliance with relevant safety and performance standards.
The Vicor VP-D2927817 has an output power of 300 W.
The input voltage range for the VP-D2927817 is 90 VAC to 132 VAC and 180 VAC to 264 VAC.
The Vicor VP-D2927817 measures 80 mm in width and 172.7 mm in length.
The Vicor VP-D2927817 holds CE, cTUVus, EN60950-1, and UL60950-1 approvals.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
