VIT-75 The VIT-75 is a single-channel video isolation transformer from Allen Bradley. It is designed to eliminate 60 Hz hum caused by ground loops.
Mfr Part #:

VIT-75

Available from 1 distributors
Mfr Name: Allen Bradley
Allen Bradley
The VIT-75 is a single-channel video isolation transformer from Allen Bradley. It is designed to eliminate 60 Hz hum caused by ground loops.
✓ Total Stock: 7 pcs
$ Price Range: $255.00

VIT-75 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
7 pcs
On Request
7 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

VIT-75 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
DC Voltage
Dimensions
Impedance
Insertion Loss
Return Loss
Weight
View Similar Products (0)

VIT-75 Description

Short technical summary and product information.

The Allen Bradley VIT-75 is a video isolation transformer designed for eliminating 60 Hz hum caused by ground loops in broadcast systems. It provides electrical isolation between the input and output, helping to eliminate induced currents in long cable runs.



Key specifications include a 75 Ohm impedance and a bandwidth of 20 Hz to 6 MHz. The device offers a minimum video isolation of 100 Megohms and a maximum insertion loss of 1 dB. It also features a minimum return loss of 20 dB.



This passive device requires no power and is housed in a high-impact ABS plastic enclosure. Its dimensions are 2.76" x 2.024" x 1.654" and it weighs 1 Lb. Mounting is facilitated by integrated mount holes.

VIT-75 Quick Information

Product Type: Video Isolation Transformer
Series: VIT
Canonical Name: VIT-75 Video Isolation Transformer
Subcategory: Video Isolation Transformer

VIT-75 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

VIT-75 Estimated Pricing

Qty Low High
1+ $255.00 $255.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

VIT-75 Features

  • Eliminates 60 Hz hum from ground loops.
  • Provides electrical isolation between input and output.
  • 75 Ohm impedance, 20 Hz to 6 MHz bandwidth.
  • 100 Megohms minimum video isolation.
  • Passive device, no power required.

VIT-75 Applications

  • Eliminates 60 Hz hum from ground loops.
  • Provides electrical isolation between input and output.
  • Used in broadcast systems with ground potential differences.
  • Eliminates induced currents in long cable runs.
  • Suitable for video signal isolation applications.

VIT-75 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the impedance of the VIT-75?

The impedance of the VIT-75 is 75 Ohms.

What is the bandwidth of the VIT-75?

The bandwidth of the VIT-75 is 20 Hz to 6 MHz.

What is the insertion loss of the VIT-75?

The maximum insertion loss for the VIT-75 is 1 dB.

What is the return loss of the VIT-75?

The minimum return loss for the VIT-75 is 20 dB.

What is the video isolation of the VIT-75?

The VIT-75 provides a minimum video isolation of 100 Megohms.

What is the hum reduction capability of the VIT-75?

The VIT-75 offers a minimum hum reduction of 100 Megohms.

What is the package type of the VIT-75?

The VIT-75 is housed in a high-impact ABS plastic enclosure.
