| Category | |
| Manufacturer Name | |
| Conflict Minerals | |
| Duration | |
| Efficiency | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Input Voltage | |
| Lead Style | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel |
The Vicor VI-MU1-EQ-BM is an enclosed AC DC converter designed for ITE (Commercial) applications. It provides a single 12V output with a current rating of 33.333A, delivering a total power of 400W. The converter operates with a universal input voltage range of 90-132 VAC and 180-264 VAC, offering flexibility in power sourcing.
Key electrical specifications include an efficiency of 88% and an isolation voltage of 4.242 kV. The operating temperature range is from 0°C to 85°C. This model features adjustable output and remote sense capabilities, enhancing its usability in various designs.
Mechanically, the VI-MU1-EQ-BM is designed for chassis mounting, with dimensions of 9.25" L x 4.90" W x 1.37" H (234.8mm x 124.5mm x 34.8mm). It is supplied in bulk packaging.
Environmental compliance information indicates it is REACH Affected and RoHS non-compliant, with a Moisture Sensitivity Level (MSL) of 1 (Unlimited).
The input voltage range is 90-132 VAC and 180-264 VAC.
The output voltage is 12V and the output current is 33.333A.
The operating temperature range is 0°C to 85°C.
The efficiency is 88%.
The isolation voltage is 4.242 kV.
It uses chassis mount packaging.
