VGS-35C-24-B
CUI Inc.
The CUI Inc. VGS-35C-24-B is an enclosed AC-DC converter providing a 24Vdc output at 1.5A, delivering 36W of power. It features a universal input range and chassis mount.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Frequency | |
| Input Voltage | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Temperature Coefficient | |
| Type | |
| Voltage |
The CUI Inc. VGS-35C-24-A is an internal AC-DC power supply designed for various applications, including household appliances and ITE commercial equipment. It offers a stable 24Vdc output with a maximum current of 1.5A and a total power output of 36W.
This converter features a universal input range of 85-264 VAC and an efficiency of up to 88%. Key protections include short-circuit, over-current, and over-voltage protection, ensuring reliable operation. The output voltage is adjustable by +/- 10% via a built-in trim pot.
With a chassis mount type and an enclosed form factor, the VGS-35C-24-A has dimensions of 99.0mm x 82.0mm x 30.0mm. It is designed to meet stringent safety and compliance standards, including UL/EN/IEC 62368, IEC/EN 61558, and IEC/EN 60335.
The output voltage is 24 Vdc.
The maximum output current is 1.5 A.
The power rating is 36W.
The input voltage range is 85 to 264 VAC.
The typical efficiency is 88%.
Yes, the output is adjustable by ±10% via a built-in trim pot.
It is certified to UL/EN/IEC 62368 and designed to meet IEC/EN 61558, IEC/EN 60335, and GB4943.
