The CUI Inc. VGD-35-D512 is a versatile AC-DC power supply designed for various applications, including household appliances and ITE commercial equipment. It provides two independently isolated outputs: a 5V rail capable of 0.4A and a 12V rail capable of 0.1A, with a maximum combined power of 32W.
This power supply operates with a universal input voltage range of 85-264 Vac and features a typical efficiency of 81%. It includes essential protections such as short circuit, over current, and over voltage protection. The unit is designed to meet safety standards like IEC/EN/UL 62368 and IEC/EN/UL 60335, and exhibits Class B EMI performance according to CISPR32/EN55032.
Mechanically, the VGD-35-D512 has dimensions of 97.0mm x 92.5mm x 30.0mm and is designed for chassis mounting with free air convection cooling. Its features include adjustable output for the 5V rail and a hold-up time of 5ms at 115 Vac and 30ms at 230 Vac.
The VGD-35-D512 provides a 5 Vdc output and a 12 Vdc output.
The maximum total combined output power for the VGD-35-D512 is 4W.
The VGD-35-D512 has a typical efficiency of 81%.
The operating temperature range is -30°C to 70°C, with derating.
The VGD-35-D512 is safety certified to IEC/EN/UL 62368 and designed to meet IEC/EN/UL 60335.
Yes, the VGD-35-D512 features short circuit protection with hiccup, continuous, self-recovery mode.
