| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Frequency | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage |
The CUI Inc. VF-S250-24A-CF is a versatile AC-DC power supply designed for various applications. It provides a continuous output power of 250W with a nominal output voltage of 24V and a maximum output current of 10.42A. The unit operates with an input voltage range of 90-264 Vac and boasts an efficiency of up to 83%.
Key features include passive power factor correction (PFC), remote on/off control, and 3000 Vac isolation voltage. It offers comprehensive protections such as over-voltage, over-current, short-circuit, and over-temperature protection. The power supply is designed for chassis mounting and has dimensions of 127.0mm x 81.3mm x 50.8mm.
Safety approvals include UL, cUL, and TUV 62368-1, making it suitable for ITE (Commercial) applications. The operating temperature range is 0°C to 70°C with derating.
The output voltage is 24 Vdc.
The maximum output current is 10.42 A.
The maximum power output is 250W.
The efficiency is typically 83%.
The input voltage range is auto selectable from 90 to 264 Vac.
The dimensions are 127.0mm x 81.3mm x 50.8mm.
The operating temperature range is 0°C to 70°C.
