| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Frequency | |
| Isolation | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| Standard Number | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The XP Power VCP24US05-E is an AC-DC converter designed for board mount applications. It provides a single 5V output with a maximum current of 2.5A, delivering up to 24W of power.
Key electrical specifications include a wide input voltage range of 90-264 VAC and an efficiency of 73%. The converter is designed for reliable operation with features like overvoltage protection, overload protection, and short circuit protection.
This model is suitable for ITE (Commercial) and Medical applications, indicated by its approval agencies including cUL, IEC, and EN standards. It is housed in a 5-DIP Module package and utilizes a Through Hole mounting type.
The operating temperature range is 0°C to 70°C with derating, and it offers natural convection cooling. The dimensions are 79.0mm x 46.0mm x 28.5mm.
The output voltage is 5V.
The maximum output current is 2.5A.
The power rating is 24W.
The input voltage range is 90-264 VAC.
The operating temperature range is 0°C to 70°C.
It is in a 5-DIP Module package.
Safety approvals include cUL, IEC, and EN standards such as EN60950-1 and EN60601-1.
