UWT0J101MCL1GB The Nichicon UWT0J101MCL1GB is a 100μF, 6.3V dc surface mount aluminum electrolytic capacitor with ±20% tolerance. It features a cylindrical can construction, 1000h lifetime, and AEC-Q200 automotive qualification.
Mfr Part #:

UWT0J101MCL1GB

Available from 1 distributors
Mfr Name: Nichicon
Nichicon
The Nichicon UWT0J101MCL1GB is a 100μF, 6.3V dc surface mount aluminum electrolytic capacitor with ±20% tolerance. It features a cylindrical can construction, 1000h lifetime, and AEC-Q200 automotive qualification.
✓ Total Stock: 979 pcs
$ Price Range: $0.02

UWT0J101MCL1GB Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
979 pcs
On Request
979 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UWT0J101MCL1GB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Construction
Country of Origin
Diameter
Failure Rate
Height
Lead Style
Length
SVHC Present
Tolerance
Voltage
View Similar Products (0)

UWT0J101MCL1GB Description

Short technical summary and product information.

The Nichicon UWT0J101MCL1GB is a surface mount aluminum electrolytic capacitor from the WT series. It offers a capacitance of 100μF with a rated voltage of 6.3V dc and a tolerance of ±20%. The capacitor is polar and features a cylindrical can construction with solder termination pins (2 pins).



This component is designed for a wide operating temperature range from -55°C to 105°C, making it suitable for demanding environments. It has a ripple current rating of 60mA and a leakage current of 3μA. The rated lifetime is 1000 hours under nominal conditions.



The capacitor meets the AEC-Q200 automotive standard, indicating reliability for automotive applications. The surface mount package has a diameter of 6.3mm and a height of 5.4mm, suitable for compact PCB assemblies. It is manufactured in Japan.

UWT0J101MCL1GB Quick Information

Product Type: Aluminium Electrolytic Capacitor
Series: UWT
Canonical Name: Nichicon WT Series 100 μF Capacitor 6.3V dc
Subcategory: Surface Mount Aluminum Electrolytic Capacitor

UWT0J101MCL1GB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

UWT0J101MCL1GB Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

UWT0J101MCL1GB Features

  • 100μF capacitance with 6.3V dc voltage rating.
  • ±20% tolerance for general purpose applications.
  • AEC-Q200 certified for automotive use.
  • Surface mount cylindrical can package.
  • Operating temperature range -55°C to 105°C.

UWT0J101MCL1GB Applications

  • Suitable for automotive engine control modules.
  • Designed for high density PCB mounting.
  • Ideal for power supply filtering circuits.
  • Used in wide temperature range applications.
  • Compatible with automatic mounting machines.

UWT0J101MCL1GB FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance value of the UWT0J101MCL1GB?

100μF.

What is the rated voltage?

6.3V dc.

What is the capacitance tolerance?

±20%.

What is the operating temperature range?

-55°C to 105°C.

What is the rated lifetime?

1000 hours.

Is this capacitor qualified for automotive use?

Yes, it meets AEC-Q200.

What is the ripple current rating?

60mA.
