| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7,500 pcs
|
7500 pcs | On Request | 1 | On Request | On Request | 17+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Input Voltage | |
| Output Voltage | |
| Storage Temperature |
The Renesas UPD166108GR-E1-AY is an N-channel low-side driver designed for switching 14V DC grounded loads. It incorporates essential protection features, including current limitation and overtemperature protection, to prevent device destruction and degradation. The driver also provides a self-diagnostic signal.
Key electrical characteristics include a maximum channel temperature of 175°C and a low on-state resistance of 200 mW MAX. at 5.0V VIN and 0.9A IO. The device supports high temperature operation and includes a built-in dynamic clamp circuit.
This component is supplied in a Power SOP 8 package, suitable for various 14V DC applications such as switching inductive, resistive, and capacitive loads. The dual-channel design offers flexibility in system implementation.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.40 | $6.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum channel temperature is 175°C.
The UPD166108GR-E1-AY includes current limitation and overtemperature protection.
The on-state resistance is a maximum of 200 mW.
The UPD166108GR-E1-AY is supplied in a Power SOP 8 package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
