UP3B-330-R The Eaton - Electronics Division UP3B-330-R is a fixed inductor with 22µH inductance and a 2.8A current rating. It features a wirewound ferrite core and surface mount packaging.
Mfr Part #:

UP3B-330-R

Available from 1 distributors
Mfr Name: Eaton - Electronics Division
Eaton - Electronics Division
The Eaton - Electronics Division UP3B-330-R is a fixed inductor with 22µH inductance and a 2.8A current rating. It features a wirewound ferrite core and surface mount packaging.
✓ Total Stock: 7 pcs
$ Price Range: $0.18

UP3B-330-R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Hybrid Electronics ✓
Non-Authorised Inventory information
7 pcs
On Request
7 pcs On Request 1 On Request On Request NO DC On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UP3B-330-R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Core Material
Current Rating
Current Saturation
DC Resistance
Inductance
Mounting Type
Operating Temperature
Shielding
Tolerance
Type
View Similar Products (0)

UP3B-330-R Description

Short technical summary and product information.

The Eaton - Electronics Division UP3B-330-R is a fixed inductor from the UNI-PAC™ series. It offers a nominal inductance of 22 µH with a tolerance of ±20%, tested at 100 kHz. This wirewound, unshielded inductor has a ferrite core and is designed for surface mount applications.



Key electrical specifications include a current rating of 2.8 A and a saturation current of 2A. The maximum DC resistance (DCR) is 61.7 mOhm. The operating temperature range is -40°C to 85°C.



Packaged in Tape & Reel (TR), this component is suitable for automated assembly processes. Its robust construction and electrical characteristics make it a reliable choice for various electronic circuits requiring stable inductance.

UP3B-330-R Quick Information

Product Type: Fixed Inductor
Series: UNI-PAC™
Canonical Name: Eaton - Electronics Division UP3B-330-R Fixed Inductor
Subcategory: Fixed Inductors

UP3B-330-R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

UP3B-330-R Estimated Pricing

Qty Low High
1+ $0.18 $0.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

UP3B-330-R Features

  • 22µH inductance with ±20% tolerance.
  • Rated for 2.8A current.
  • Low 61.7mOhm maximum DC resistance.
  • Wirewound ferrite core construction.
  • Surface mountable for automated assembly.

UP3B-330-R Applications

  • Suitable for power supply filtering.
  • Used in signal conditioning circuits.
  • Ideal for general purpose inductance needs.
  • Component for embedded systems.

UP3B-330-R FAQs

5 frequently asked questions generated from this part’s specifications.
What is the inductance of the UP3B-330-R?

The inductance is 22 µH.

What is the current rating for the UP3B-330-R inductor?

The current rating is 2.8 A.

What is the maximum DC resistance (DCR) of this inductor?

The maximum DC resistance is 61.7 mOhm.

What type of core does the UP3B-330-R use?

It uses a ferrite core.

How is the UP3B-330-R inductor mounted?

It is a surface mount component.
