UMPS-04-03.5-L-V-S-W-TR

The Samtec UMPS-04-03.5-L-V-S-W-TR is a 4-position receptacle from the mPOWER series, designed for high-power applications in a compact 2.00mm pitch. This vertical surface mount connector features female blade sockets and is rated for up to 18A per contact (with one blade powered) and 650VDC. The insulator is black LCP, and contacts are copper alloy with 10µ" gold on the contact area and matte tin on the solder tails. The operating temperature range is -55°C to +105°C for this tin plating variant.

This connector includes solder retention features and weld tabs for secure mounting. It is supplied in tape and reel packaging with 575 pieces per reel, with a lead style of 3.5mm resulting in a mated stack height of 5mm when used with the corresponding UMPT header. The UMPS series supports board-to-board, cable-to-board, and cable-to-cable configurations, offering design flexibility for power distribution in industrial, automotive, and telecom equipment.

The part is lead-free solderable and has an MSL rating of 1 (unlimited floor life). Compliance with RoHS and REACH is indicated but unverified. This connector is suitable for applications requiring high current density in a small footprint.
