UMPS-02-07.5-L-V-S-W-TR Samtec UMPS-02-07.5-L-V-S-W-TR is a 2mm pitch ultra micro power blade receptacle with 2 female blade sockets. It features vertical surface mount termination, 7.5mm terminal height, gold plating, and is rated for 16.3A per contact.
Mfr Part #:

UMPS-02-07.5-L-V-S-W-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec UMPS-02-07.5-L-V-S-W-TR is a 2mm pitch ultra micro power blade receptacle with 2 female blade sockets. It features vertical surface mount termination, 7.5mm terminal height, gold plating, and is rated for 16.3A per contact.
✓ Total Stock: 55 pcs
$ Price Range: $2.24 - $4.23

UMPS-02-07.5-L-V-S-W-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
55 pcs
On Request
55 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UMPS-02-07.5-L-V-S-W-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Connector Type
Contact Material
Contact Plating
Current Rating (Per Contact)
Features
Halogen Free
Insulator Material
Lead Spacing
Lead Style
Mounting Type
Number of Positions
Number of Rows
Operating Temperature Range
Orientation
Pitch
Tape & Reel
Termination
Termination Style
View Similar Products (0)

UMPS-02-07.5-L-V-S-W-TR Description

Short technical summary and product information.

The Samtec UMPS-02-07.5-L-V-S-W-TR is a 2mm pitch ultra micro power blade receptacle from the mPOWER series. It features 2 female blade socket contacts in a vertical surface mount configuration with a 7.5mm terminal height. The contact plating is 10µ" gold on the contact area with matte tin on the tail, and the insulator is black LCP. This connector includes a weld tab for additional mechanical retention and is designed with solder retention features.



Electrically, each contact is rated for 16.3A maximum (derated 20% with 30°C rise) and the connector can handle 460 VAC or 650 VDC. The creepage distance is 2.20mm and clearance is 1.65mm. The operating temperature range is -55°C to +125°C with gold plating.



This receptacle is part of Samtec's mPOWER system, which offers board-to-board, cable-to-board, and cable-to-cable solutions for high power in a small form factor. It is Severe Environment Testing (SET) qualified and aligns with MIL-DTL-55302 standards.



Packaging is Tape & Reel with a standard quantity of 350 parts per reel. The part is lead-free solderable and RoHS3 compliant (unverified).

UMPS-02-07.5-L-V-S-W-TR Quick Information

Product Type: Power Blade Receptacle
Series: UMPS
Canonical Name: Samtec UMPS-02-07.5-L-V-S-W-TR - 2mm Ultra Micro Power Blade Receptacle, 2 Position, Vertical SMT, 7.5mm Height, Gold Plating
Subcategory: Surface Mount Power Blade Receptacle

UMPS-02-07.5-L-V-S-W-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

UMPS-02-07.5-L-V-S-W-TR Estimated Pricing

Qty Low High
1+ $4.23 $4.23
10+ $3.60 $3.60
25+ $3.37 $3.37
50+ $3.21 $3.21
100+ $3.06 $3.06
350+ $2.24 $2.24

Estimated market price range - modelled values for guidance only, not live distributor offers.

UMPS-02-07.5-L-V-S-W-TR Features

  • 2mm pitch ultra micro power blade design.
  • Rated for 16.3A per contact.
  • Vertical surface mount with solder retention.
  • Gold plating on contact area.
  • Weld tab for additional mechanical stability.

UMPS-02-07.5-L-V-S-W-TR Applications

  • Ideal for high-density power distribution.
  • Used in board-to-board power connections.
  • Suitable for severe environment applications.
  • Compatible with mPOWER cable assemblies.

UMPS-02-07.5-L-V-S-W-TR FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the UMPS-02-07.5-L-V-S-W-TR have?

2 positions.

What is the pitch of this connector?

2.00mm (0.079 inches).

What is the current rating per contact?

16.3A maximum (derated 20% with 30°C rise).

What is the voltage rating?

460 VAC and 650 VDC.

What is the mounting type?

Surface Mount.

What is the operating temperature range?

-55°C to +125°C with gold plating.

What is the contact plating?

10µ" Gold on contact, Matte Tin on tail.
