TLV431BCDBZTG4
Texas Instruments
The Texas Instruments TLV431BCDBZTG4 is an adjustable precision shunt regulator. It offers a wide output voltage range and low operational current.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200,000 pcs
|
200000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Operating Temperature Range | |
| SVHC Present |
The ULQ2003ATDRQ1 from Texas Instruments is a high-voltage, high-current Darlington transistor array designed for automotive applications. Each device contains seven npn Darlington pairs, each rated for a 50V switching voltage and 500mA peak output current. The outputs are equipped with common-cathode clamp diodes, making them suitable for switching inductive loads.
This array features a 2.7kΩ series base resistor for each Darlington pair, enabling direct operation with TTL or 5V CMOS devices. The typical delay time is 1000ns, and the input is compatible with CMOS and TTL logic levels. The operating temperature range is from -40°C to 125°C.
The ULQ2003ATDRQ1 is available in multiple package options including TSSOP (16 pins, 32 mm²), SOIC (16 pins, 59.4 mm²), and SOT-23-THN (16 pins, 8.4 mm²). Its design includes ESD protection exceeding 200V (machine model) and high-voltage outputs up to 50V.
This component is qualified for automotive applications and is well-suited for relay-driver applications and other high-power switching tasks where robust performance and high voltage handling are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.25 | $0.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum switching voltage is 50V.
The ULQ2003ATDRQ1 is available in TSSOP (PW), SOIC (D), and SOT-23-THN (DYY) packages.
-40°C to 125°C.
0.5A per channel.
7 drivers per package.
CMOS and TTL.
1000 nanoseconds.
