UEI-5/10-Q12NR-C The Murata UEI-5/10-Q12NR-C is a 50W DC DC converter with a 5V output and 10A maximum current. It is an isolated module designed for through-hole mounting.
Mfr Part #:

UEI-5/10-Q12NR-C

Available from 1 distributors
Mfr Name: Murata
Murata
The Murata UEI-5/10-Q12NR-C is a 50W DC DC converter with a 5V output and 10A maximum current. It is an isolated module designed for through-hole mounting.
✓ Total Stock: 30 pcs
$ Price Range: $2.70

UEI-5/10-Q12NR-C Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Rayichip ✓
Non-Authorised Inventory information
30 pcs
On Request
30 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UEI-5/10-Q12NR-C Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Control Features
Current
Efficiency
Failure Rate
Features
Height
Length
Mounting Type
Number of Outputs
Operating Temperature
Power (Watts)
Type
Voltage
Width
View Similar Products (0)

UEI-5/10-Q12NR-C Description

Short technical summary and product information.

The Murata UEI-5/10-Q12NR-C is a 50W DC DC converter featuring an isolated module design. It provides a single 5V output with a maximum current of 10A, operating within an input voltage range of 9V to 36V.



This converter is designed for ITE (Commercial) applications and includes features such as Remote On/Off, OCP, OTP, OVP, and SCP for enhanced control and protection. It has an efficiency of 90% and an isolation voltage of 2.25 kV.



The physical specifications include a through-hole mounting type and dimensions of 48.3mm x 38.1mm x 9.7mm. The operating temperature range is -40°C to 85°C, making it suitable for various environmental conditions.

UEI-5/10-Q12NR-C Quick Information

Product Type: DC DC Converter
Series: UEI (50W)
Canonical Name: Murata UEI-5/10-Q12NR-C DC DC Converter
Subcategory: Isolated Module

UEI-5/10-Q12NR-C Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

UEI-5/10-Q12NR-C Estimated Pricing

Qty Low High
1+ $2.70 $2.70

Estimated market price range - modelled values for guidance only, not live distributor offers.

UEI-5/10-Q12NR-C Features

  • Isolated module DC DC converter.
  • 5V output at 10A maximum current.
  • Wide 9V to 36V input voltage range.
  • Through hole mounting for easy integration.
  • Operates from -40°C to 85°C.

UEI-5/10-Q12NR-C Applications

  • Power for industrial control systems.
  • Suitable for telecom equipment.
  • Used in distributed power architectures.
  • Ideal for battery-powered systems.
  • Provides isolated 5V supply for electronics.

UEI-5/10-Q12NR-C FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating temperature range of the UEI-5/10-Q12NR-C?

-40°C to 85°C.

What is the input voltage range for this converter?

9V to 36V.

What is the output voltage and current?

5V at 10A.

What is the isolation voltage?

2.25 kV.

What efficiency does the converter achieve?

90%.

What protection features are included?

Remote On/Off, OCP, OVP, OTP, SCP.

What is the package type?

9-DIP Module, 8 Leads, Through Hole.
