Mfr Part #:

UCC5304DWVR

Name: UCC5304DWVR
Brand: Texas Instruments
SKU: UCC5304DWVR

Mfr Name: Texas Instruments

Description:

4A/6A 5.7KVRMS SING CH ISODR 5V

Stock on Request

UCC5304DWVR Description

Short technical summary and product information.

4A/6A 5.7KVRMS SING CH ISODR 5V

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Same form/fit/function or matching attribute configuration across different manufacturers.

UCC5304DWV

Texas Instruments

4A/6A 5.7KVRMS SING

Category	Isolators - Gate Drivers
Manufacturer Name	Texas Instruments
Approval Agency	CQC, UL, VDE
Common Mode Transient Immunity (Min)	100V/ns
Current	4A, 6A
Mounting Type	Surface Mount
Number of Channels	1
Operating Temperature	-40°C ~ 125°C
Propagation Delay tpLH	40ns, 40ns
Pulse Width Distortion (Max)	5.5ns
Rise	5ns, 6ns
Supplier Device Package	8-SOIC
Technology	Capacitive Coupling
Voltage	6V ~ 18V
