| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
15,067 pcs
|
15067 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3,569 pcs
|
3569 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Mounting Type | |
| Operating Temperature | |
| Supplier Device Package | |
| Supplier Package | |
| Voltage |
The UCC29002D from Texas Instruments is an advanced, high-performance load share controller. It provides essential functions for paralleling multiple independent power supplies or DC-to-DC modules, making it suitable for N+1 redundant systems or high-current applications.
This controller boasts high accuracy, capable of less than 1% current-share error at full load. It supports both high-side and low-side current sensing and is compliant with the Intel SSI load share specification. The device operates over a voltage range of 4.375V to 14.25V and an extended temperature range of -40°C to 105°C.
Packaged in an 8-SOIC (0.154", 3.90mm Width) surface mount package, the UCC29002D is designed for efficient integration into distributed power systems found in servers, workstations, and telecom equipment. Its features include a single-wire load-share bus and protection against shorts to GND or the supply rail.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.16 | $2.16 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -40°C to 105°C.
The operating voltage range is 4.375V to 14.25V.
The current consumption is 2.5mA.
It complies with the Intel SSI load share specification.
The current share error is less than 1% at full load.
It supports high-side or low-side current sensing.
The UCC29002D is available in an 8-SOIC package.
