UCC27712DR The Texas Instruments UCC27712DR is a 620V half-bridge gate driver designed for IGBT and MOSFET power switches. It features dual non-inverting drivers with interlock and dead-time control.
Mfr Part #:

UCC27712DR

Available from 4 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments UCC27712DR is a 620V half-bridge gate driver designed for IGBT and MOSFET power switches. It features dual non-inverting drivers with interlock and dead-time control.
✓ Total Stock: 63,569 pcs
$ Price Range: $0.74

UCC27712DR Available from 4 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
54,788 pcs
On Request
54788 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
7,075 pcs
On Request
7075 pcs On Request 1 On Request On Request 21+ On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
1,259 pcs
On Request
1259 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
447 pcs
On Request
447 pcs On Request 1 On Request On Request 19+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UCC27712DR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Channel Type
Current
Driven Configuration
Gate Type
High Side Voltage
Logic Voltage
Mounting Type
Number of Drivers
Operating Temperature
Quiescent Current
Rise
Storage Temperature
Supplier Device Package
Tape & Reel
Voltage
View Similar Products (0)

UCC27712DR Description

Short technical summary and product information.

The Texas Instruments UCC27712DR is a high-performance half-bridge gate driver IC. It is designed to drive IGBT and N-channel/P-channel MOSFET power switches efficiently.



This device operates with an input supply voltage range of 10V to 20V and can handle high-side voltages up to 620V. It provides a peak output current of 2.8A sink and 1.8A source. Key features include integrated dead-time control and an interlock function to prevent shoot-through.



The UCC27712DR operates over a wide temperature range of -40°C to 150°C. It is available in an 8-SOIC package, suitable for surface mount applications. The driver configuration is dual and non-inverting, with TTL and CMOS compatible inputs.



This gate driver is well-suited for various power conversion applications requiring robust control of half-bridge power stages. Its specifications ensure reliable operation in demanding environments.

UCC27712DR Quick Information

Product Type: Gate Driver
Canonical Name: UCC27712DR 620V Half-Bridge Gate Driver
Subcategory: Half-Bridge Driver

UCC27712DR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

UCC27712DR Estimated Pricing

Qty Low High
1+ $0.74 $0.74

Estimated market price range - modelled values for guidance only, not live distributor offers.

UCC27712DR Features

  • Drives IGBT and MOSFET power switches.
  • 620V high-side voltage capability.
  • 1.8A source, 2.8A sink peak output.
  • Integrated dead-time control and interlock.
  • Operates from -40°C to 150°C.

UCC27712DR Applications

  • Suitable for half-bridge power stages.
  • Used in power supply designs.
  • Ideal for motor control circuits.
  • Applicable in industrial systems.

UCC27712DR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the UCC27712DR?

The input supply voltage is 10 V to 20 V, with a high side voltage rating of 600 V.

What package does the UCC27712DR come in?

8-SOIC surface mount package (0.154", 3.90mm width).

What is the operating temperature range of the UCC27712DR?

-40°C to 150°C.

What is the peak output current of the UCC27712DR?

Peak output current is 2.8 A sink and 1.8 A source.

Does the UCC27712DR feature dead time control?

Yes, it includes dead time control and interlock.

What types of power switches can the UCC27712DR drive?

It can drive IGBTs, N-channel MOSFETs, and P-channel MOSFETs.

What is the propagation delay time?

Typical propagation delay is 0.1 µs.
