UCC27524DSDR The Texas Instruments UCC27524DSDR is a dual-channel, low-side gate driver IC. It offers a peak output current of 5A and operates from a 4.5V to 18V supply.
Mfr Part #:

UCC27524DSDR

Available from 5 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments UCC27524DSDR is a dual-channel, low-side gate driver IC. It offers a peak output current of 5A and operates from a 4.5V to 18V supply.
✓ Total Stock: 57,095 pcs
$ Price Range: $0.55

UCC27524DSDR Available from 5 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UCC27524DSDR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Channel Type
Current
Driven Configuration
Gate Type
Input Type
Logic Voltage
Mounting Type
Number of Drivers
Operating Temperature
Rise
Supplier Device Package
Voltage
View Similar Products (0)

UCC27524DSDR Description

Short technical summary and product information.

The Texas Instruments UCC27524DSDR is a high-speed, dual-channel, low-side gate driver designed for driving N-channel MOSFETs and IGBTs. It provides 5A of peak source and sink drive current, enabling efficient switching of power devices.



This gate driver operates from a single supply voltage ranging from 4.5V to 18V. Key electrical characteristics include a fast propagation delay of 13ns and fast rise/fall times of 7ns and 6ns, respectively. It features an undervoltage lockout (UVLO) typically at 4V, ensuring safe operation during power up and down.



The UCC27524DSDR is available in an 8-SON (3x3) package and an 8-WDFN Exposed Pad package, both suitable for surface mounting. Its independent enable function for each output and TTL/CMOS compatible logic thresholds enhance design flexibility. The device is rated for an operating temperature range of -40°C to 140°C (junction temperature).

UCC27524DSDR Quick Information

Product Type: Gate Driver
Canonical Name: UCC27524 Dual 5A, High-Speed, Low-Side Gate Driver
Subcategory: Low-Side Gate Driver

UCC27524DSDR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

UCC27524DSDR Estimated Pricing

Qty Low High
1+ $0.55 $0.55

Estimated market price range - modelled values for guidance only, not live distributor offers.

UCC27524DSDR Features

  • Dual-channel low-side gate driver.
  • 5A peak source and sink drive current.
  • Fast 13ns propagation delay.
  • Wide 4.5V to 18V supply range.
  • Surface mountable 8-SON package.

UCC27524DSDR Applications

  • Driving N-channel MOSFETs.
  • Driving IGBT power transistors.
  • High-speed power switching.
  • Power supply applications.
  • Motor control circuits.

UCC27524DSDR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the UCC27524DSDR?

The supply voltage range is 4.5V to 18V.

What is the peak output current of the UCC27524DSDR?

The peak output current is 5A per channel.

What is the operating temperature range?

The junction temperature range is -40°C to 140°C.

What packages are available for the UCC27524DSDR?

Available packages include 8-SON (3x3) and 8-WDFN with exposed pad.

What is the propagation delay of this gate driver?

The typical propagation delay is 13ns.

What gate types can this driver handle?

It can drive IGBTs and N-Channel MOSFETs.

Does the UCC27524DSDR have undervoltage lockout?

Yes, the typical UVLO threshold is 4V.
