UCC27524DR The Texas Instruments UCC27524DR is a dual low-side gate driver IC designed for GaNFET, IGBT, and MOSFET power switches. It offers a peak output current of 5A and operates from a 4.5V to 18V supply.
Mfr Part #:

UCC27524DR

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments UCC27524DR is a dual low-side gate driver IC designed for GaNFET, IGBT, and MOSFET power switches. It offers a peak output current of 5A and operates from a 4.5V to 18V supply.
✓ Total Stock: 104,632 pcs
$ Price Range: $0.55

UCC27524DR Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
100,000 pcs
On Request
100000 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
3,432 pcs
On Request
3432 pcs On Request 1 On Request On Request 1436+ On Request On Request
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
1,200 pcs
On Request
1200 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UCC27524DR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Channel Type
Current
Driven Configuration
Gate Type
Input Type
Lead Spacing
Lead Style
Logic Voltage
Mounting Type
Number of Channels
Number of Drivers
Operating Temperature
Rise
Supplier Device Package
Supplier Package
Voltage
View Similar Products (0)

UCC27524DR Description

Short technical summary and product information.

The UCC27524DR from Texas Instruments is a high-performance, dual-channel, low-side gate driver. It is designed to efficiently drive GaNFET, IGBT, and N-channel MOSFET power switches.



This device features a peak output current capability of 5A for both source and sink, ensuring robust gate drive performance. It operates from a wide input supply voltage range of 4.5V to 18V. The driver configuration is low-side, with independent channels for flexible control.



Key electrical characteristics include a propagation delay time of 0.013µs, a rise time of 7ns, and a fall time of 6ns. The input logic thresholds are compatible with CMOS and TTL standards, and the device can handle negative input voltages down to -5V. An undervoltage lockout feature typically operates at 4V, ensuring safe operation during power transitions.



The UCC27524DR is available in an 8-SOIC package, suitable for surface mount applications. Its operating temperature range is -40°C to 140°C (TJ), making it suitable for various industrial environments.

UCC27524DR Quick Information

Product Type: Gate Driver
Series: UCC27524
Canonical Name: UCC27524DR Dual Low-Side Gate Driver
Subcategory: Low-Side Gate Driver

UCC27524DR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

UCC27524DR Estimated Pricing

Qty Low High
1+ $0.55 $0.55

Estimated market price range - modelled values for guidance only, not live distributor offers.

UCC27524DR Features

  • Dual 5A peak source and sink current.
  • Wide 4.5V to 18V single supply range.
  • Fast 7ns rise and 6ns fall times.
  • Handles negative input voltages down to -5V.
  • 8-SOIC surface mount package.

UCC27524DR Applications

  • Drives GaNFET, IGBT, and MOSFETs.
  • Suitable for low-side switching applications.
  • Industrial power supply designs.
  • Motor control applications.

UCC27524DR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the UCC27524DR?

4.5V to 18V.

What is the package type?

8-SOIC surface-mount package.

What is the operating temperature range?

-40°C to 140°C (junction temperature).

How many channels does it have?

2 channels.

What is the peak output current?

5A.

What are the rise and fall times?

Rise time 7ns, fall time 6ns.

What input thresholds does it support?

CMOS and TTL.
