The Texas Instruments UCC23514MDWVR is a single-channel isolated gate driver designed for high-voltage applications. It provides reinforced isolation with a withstand voltage of 5000 Vrms and working isolation voltage of 1500 Vrms.
Key electrical specifications include a peak output current of 4.5A for sourcing and 5.3A for sinking, with an output driver supply voltage range of 14V to 33V. The device features an active miller clamp, emitter-referenced UVLO, and an opto-compatible input with split outputs.
This gate driver operates within a temperature range of -40°C to 125°C and is housed in an 8-SOIC package suitable for surface mounting. It supports power switches like IGBT, MOSFET, and SiCFET, making it versatile for various power conversion designs.
Compliance certifications include CQC, UL, and VDE. The part is also noted as RoHS3 Compliant, MSL 1 Unlimited, and REACH Unaffected, though these compliance statuses are unverified.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.63 | $0.63 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The UCC23514MDWVR has a withstand isolation voltage of 5000 Vrms and a working isolation voltage of 1500 Vrms.
The peak output current is 4.5A for sourcing and 5.3A for sinking.
The operating temperature range is -40°C to 125°C.
It is supplied in an 8-SOIC package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
