UBX-G7020-KT The U-BL UBX-G7020-KT is a GNSS chip supporting GPS/QZSS and GLONASS. It offers low power consumption, high sensitivity, and exceptional jamming immunity.
Mfr Part #:

UBX-G7020-KT

Available from 1 distributors
Mfr Name: U-BL
U-BL
The U-BL UBX-G7020-KT is a GNSS chip supporting GPS/QZSS and GLONASS. It offers low power consumption, high sensitivity, and exceptional jamming immunity.
✓ Total Stock: 1,000 pcs

UBX-G7020-KT Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

UBX-G7020-KT Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Dimensions
Interface
Mounting Type
Package / Case
View Similar Products (0)

UBX-G7020-KT Description

Short technical summary and product information.

The UBX-G7020-KT from u-blox is a u-blox 7 series GNSS chip designed for applications requiring reliable positioning. It supports GPS/QZSS and GLONASS satellite systems, providing global coverage.



Key features include minimal board space requirements (under 30 mm2), low power consumption, and high sensitivity. The chip also boasts exceptional jamming immunity, making it suitable for challenging environments. It supports crystal and TCXO oscillators and offers an open CPU standalone module operation mode.



With a supply voltage range of 1.4V to 3.6V and an operating temperature range of -40°C to 85°C, the UBX-G7020-KT is versatile. It includes interfaces such as UART, USB, SPI, and I2C. The chip supports active antenna/LNA control and supply, data logging, an internal oscillator, and programmable flash memory.



This product is pin-compatible with the UBX-M8030 series. It is available in a compact WL-CSP50 package, suitable for surface mounting. Note that this is an older generation product and is End-of-Life (EOL). For new designs, u-blox recommends the UBX-M9140 or UBX-M10 series.

UBX-G7020-KT Quick Information

Product Type: GNSS Chip
Series: UBX-G7020
Canonical Name: u-blox 7 GNSS Chip UBX-G7020-KT
Subcategory: GNSS Chip

UBX-G7020-KT Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

UBX-G7020-KT Features

  • Supports GPS/QZSS and GLONASS satellite systems.
  • Minimal board space requirement, under 30 mm2.
  • Combines low power consumption and high sensitivity.
  • Exceptional jamming immunity for reliable performance.
  • Operating temperature range from -40°C to 85°C.

UBX-G7020-KT Applications

  • Suitable for autonomous robotic lawn mowers.
  • Used in autonomous vehicles and drones.
  • Applicable in precision agriculture systems.
  • Supports connected factory and logistics tracking.
  • Ideal for asset and personal tracking devices.

UBX-G7020-KT FAQs

7 frequently asked questions generated from this part’s specifications.
What GNSS constellations does the UBX-G7020-KT support?

GPS/QZSS and GLONASS.

What is the operating temperature range?

-40°C to 85°C.

What is the supply voltage range?

1.4V to 3.6V.

What package is the UBX-G7020-KT offered in?

WL-CSP50.

Does the module have an internal antenna?

Yes, it has an internal antenna and also supports both active and passive external antennas.

What interfaces are available?

UART, USB, SPI, and I2C.

What is the module size?

5 x 5 x 0.59 mm.
