Mfr Part #:

TXR40AB00-2414BI

TE Connectivity TXR40AB00-2414BI is a backshell heat shrink adapter with shell size 25 J, M37x1 thread, 180° cable exit, olive drab cadmium plated aluminum alloy, shielded with Tinel Lock feature, and environment resistant.

✓ Total Stock: 4 pcs

$ Price Range: $482.87 - $523.51

TXR40AB00-2414BI Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Speed Components Ltd ✓ Non-Authorised Inventory information	4 pcs On Request	4 pcs	On Request	1	On Request	On Request	1341	On Request	On Request

TXR40AB00-2414BI Description

Short technical summary and product information.

The TE Connectivity TXR40AB00-2414BI is a backshell heat shrink adapter designed for use with circular connectors. It features a shell size of 25 J with an M37x1 thread and a 180° cable exit angle. The adapter is constructed from aluminum alloy with an olive drab cadmium plating, providing corrosion resistance and durability. It is shielded for EMI protection and includes a Tinel Lock mechanism for secure cable retention. The adapter is environment resistant, suitable for harsh conditions. It has a diameter of 43.50mm (1.713"). The part is RoHS3 compliant, REACH unaffected, and has an MSL level of 1 (unlimited).

TXR40AB00-2414BI Quick Information

Product Type: Backshell, Heat Shrink Adapter

Series: TXR40AB00

Canonical Name: TE Connectivity TXR40AB00-2414BI Backshell, Heat Shrink Adapter, Shell Size 25 J, Olive Drab, Cadmium Plated

Subcategory: Heat Shrink Adapters

TXR40AB00-2414BI Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TXR40AB00-2414BI Estimated Pricing

Qty	Low	High
1+	$523.51	$523.51
10+	$513.04	$513.04
50+	$502.78	$502.78
100+	$492.73	$492.73
500+	$482.87	$482.87

Estimated market price range - modelled values for guidance only, not live distributor offers.

TXR40AB00-2414BI Features

Backshell heat shrink adapter for circular connectors.
Shell size 25 J with M37x1 thread.
180° cable exit with shielded construction.
Olive drab cadmium plated aluminum alloy.
Tinel Lock feature for secure cable retention.

TXR40AB00-2414BI Applications

For cable strain relief and shielding in connector systems.
180° cable exit for straight cable routing.
Shielded construction for EMI protection.
Environment resistant for outdoor applications.
Tinel Lock for secure attachment.

TXR40AB00-2414BI FAQs

7 frequently asked questions generated from this part’s specifications.

What is the shell size of the TXR40AB00-2414BI backshell?

Shell size 25, J.

What thread size does this backshell adapter have?

M37x1.

What is the cable exit angle?

180°.

Is this backshell shielded?

Yes, it is shielded.

What material and plating are used?

Aluminum alloy with olive drab cadmium plating.

Does it feature a Tinel Lock?

Yes, it includes a Tinel Lock mechanism.

What is the ingress protection rating?

Environment resistant.
