| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,018 pcs
|
2018 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact System | |
| Halogen Free | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Orientation | |
| Overall Length | |
| Packaging Type | |
| Performance | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Stack Height | |
| Tail Length | |
| Tape & Reel | |
| Termination |
The Samtec TW-03-03-L-D-180-126 is a 6-position, 2-row board stacker header from the TW-TH series. It features a 2.00mm (0.079") pitch and is designed for through-hole mounting, making it suitable for elevated board stacking applications.
This connector has a stack height of 0.180 inches and an overall length of 0.535 inches. The contacts are 0.020" square posts with a 10µin gold finish, ensuring reliable connections. The tail length is 0.126 inches. The housing is black in color.
The TW-03-03-L-D-180-126 supports data rates up to 8 Gbps, making it suitable for high-speed signal transmission. It is designed for use in applications requiring flexible stacking heights, such as mezzanine or board-to-board connections. The FleXYZ feature provides design flexibility in all three axes.
This part is supplied in bulk packaging. It is RoHS3 compliant and REACH unaffected, with an MSL of 1 (unlimited). Note: Compliance status is unverified; please refer to manufacturer documentation for confirmation.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.22 | $1.22 |
| 50+ | $0.98 | $0.98 |
| 100+ | $0.78 | $0.78 |
| 500+ | $0.63 | $0.63 |
| 1,000+ | $0.61 | $0.61 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 6 positions (2 rows of 3).
The pitch is 2.00mm (0.079 inches).
Through-hole mounting.
0.180 inches.
Up to 8 Gbps.
Gold with 10µin thickness.
2 rows.
