TUSB1105RTZR The Texas Instruments TUSB1105RTZR is an advanced universal serial bus transceiver compliant with USB Specification Rev. 2.0. It supports both full-speed (12-Mbit/s) and low-speed (1.5-Mbit/s) data rates.
Mfr Part #:

TUSB1105RTZR

Available from 2 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TUSB1105RTZR is an advanced universal serial bus transceiver compliant with USB Specification Rev. 2.0. It supports both full-speed (12-Mbit/s) and low-speed (1.5-Mbit/s) data rates.
✓ Total Stock: 1,799 pcs
$ Price Range: $0.87

TUSB1105RTZR Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,619 pcs
On Request
1619 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
180 pcs
On Request
180 pcs On Request 1 On Request On Request 11+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TUSB1105RTZR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Data Rate
Duplex
Lead Spacing
Mounting Type
Number of Drivers
Operating Temperature
Operating Voltage
Package Quantity
Protocol
Receiver Hysteresis
Supplier Device Package
Supplier Package
Tape & Reel
Type
Voltage
View Similar Products (0)

TUSB1105RTZR Description

Short technical summary and product information.

The TUSB1105RTZR from Texas Instruments is a versatile universal serial bus (USB) transceiver designed to meet the requirements of the Universal Serial Bus Specification Rev. 2.0. This device is capable of transmitting and receiving serial data at both full-speed (12-Mbit/s) and low-speed (1.5-Mbit/s) data rates, making it suitable for a wide range of USB applications.



Key electrical characteristics include an operating voltage range of 1.65 V to 3.6 V and a receiver hysteresis of 450 mV. The transceiver operates in half-duplex mode and supports a 1/1 driver/receiver configuration. It is designed for low-power operation, making it an ideal choice for portable equipment.



The TUSB1105RTZR is housed in a 16-WQFN exposed pad package, suitable for surface mounting. It operates within an ambient temperature range of -40°C to 85°C. The device also features IEC-61000-4-2 ESD compliance with +/-9kV contact discharge and +/-15kV human-body model protection.

TUSB1105RTZR Quick Information

Product Type: USB Transceiver
Canonical Name: TUSB1105RTZR Universal Serial Bus Transceiver
Subcategory: USB Transceiver

TUSB1105RTZR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TUSB1105RTZR Estimated Pricing

Qty Low High
1+ $0.87 $0.87

Estimated market price range - modelled values for guidance only, not live distributor offers.

TUSB1105RTZR Features

  • Compliant with Universal Serial Bus Specification Rev. 2.0.
  • Supports 1.5-Mbit/s and 12-Mbit/s data rates.
  • Operates from 1.65 V to 3.6 V I/O voltage.
  • Half-duplex transceiver in 16-WQFN package.
  • Wide -40°C to 85°C operating temperature range.

TUSB1105RTZR Applications

  • Ideal for portable electronic devices.
  • Suitable for USB device or host applications.
  • Used in mobile phones and PDAs.
  • Applicable for digital still cameras.

TUSB1105RTZR FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the TUSB1105RTZR?

The TUSB1105RTZR supports an I/O voltage range from 1.65 V to 3.6 V.

What package type is the TUSB1105RTZR available in?

The TUSB1105RTZR is available in a 16-WQFN exposed pad package.

What is the operating temperature range for this USB transceiver?

The TUSB1105RTZR operates in a temperature range of -40°C to 85°C.

Does the TUSB1105RTZR comply with RoHS standards?

Yes, the TUSB1105RTZR is RoHS3 Compliant.
