TSW-150-08-L-S 50 position single row unshrouded header with 2.54mm pitch, through hole mounting, and tin plated phosphor bronze contacts.
Mfr Part #:

TSW-150-08-L-S

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
50 position single row unshrouded header with 2.54mm pitch, through hole mounting, and tin plated phosphor bronze contacts.
✓ Total Stock: 47 pcs

TSW-150-08-L-S Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
47 pcs
On Request
47 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSW-150-08-L-S Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Insulator Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Plating
SVHC Present
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

TSW-150-08-L-S Description

Short technical summary and product information.

The Samtec TSW-150-08-L-S is a 50-position single row unshrouded header from the TSW series. It features a 2.54mm (0.100") pitch and through hole mounting with solder termination. The header is designed for board-to-board or cable connections and mates with Samtec SSW, SSQ, SSM, and other series.



Key specifications: 50 positions, 1 row, male pin contacts with square shape, tin plating over 50µ" nickel on phosphor bronze terminals. The insulator is black PBT with UL94 V-0 flammability rating. Overall contact length is 0.530" (13.46mm) with a mating pin length of 5.84mm (0.230"). Operating temperature range is -55°C to 105°C with tin plating. Voltage rating is 550 VAC and current rating is 5.7A per pin when mated with SSW series.



This header is not lead-free solderable; it is designed for lead wave soldering only. The unshrouded design allows for flexible mating with various cable assemblies and board-to-board applications.

TSW-150-08-L-S Quick Information

Product Type: Header, Male Pins
Series: TSW
Canonical Name: TSW-150-08-L-S - 50 Position Single Row Unshrouded Header
Subcategory: Unshrouded header

TSW-150-08-L-S Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TSW-150-08-L-S Features

  • 50 position single row connector.
  • 2.54mm pitch for compact designs.
  • Through hole solder termination.
  • Unshrouded design for flexibility.
  • Tin plated phosphor bronze contacts.

TSW-150-08-L-S Applications

  • Board-to-board connections in electronics.
  • Cable-to-board applications with IDC mates.
  • Ideal for prototyping and production.
  • Used in industrial control systems.

TSW-150-08-L-S FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

50 positions.

What is the pitch?

2.54mm (0.100").

What is the current rating?

5.7A per pin (mated with SSW series).

What is the voltage rating?

550 VAC (mated with SSW series).

What is the mounting type?

Through hole.

What is the operating temperature range?

-55°C to 125°C with gold plating, -55°C to 105°C with tin plating.

What is the contact finish?

Tin over 50µ" nickel.
