TSW-120-24-G-D 40 position (2x20), 2.54mm pitch through hole unshrouded male pin header with gold contacts.
Mfr Part #:

TSW-120-24-G-D

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
40 position (2x20), 2.54mm pitch through hole unshrouded male pin header with gold contacts.
✓ Total Stock: 17 pcs
$ Price Range: $2.18 - $4.16

TSW-120-24-G-D Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
17 pcs
On Request
17 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSW-120-24-G-D Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TSW-120-24-G-D Description

Short technical summary and product information.

This header is designed for classic 0.100" (2.54mm) pitch applications. It features 40 positions arranged in 2 rows with all positions loaded. The unshrouded push-pull design accommodates board-to-board or cable mating with compatible socket strips.



The phosphor bronze contacts are plated with 0.25µm gold over a 0.635mm square post. The black PBT insulator carries a UL94 V-0 flammability rating. This component is rated for an operating temperature range of -55°C to 125°C.



The 6.73mm mating contact length and 12.19mm overall contact length suit standard through hole insertion. Bulk packaging supports automated or hand assembly in prototyping and production environments.

TSW-120-24-G-D Quick Information

Product Type: Header, Male Pins
Series: TSW-120-24
Canonical Name: TSW-120-24-G-D 40 Position 2.54mm Pitch Through Hole Header
Subcategory: Unshrouded

TSW-120-24-G-D Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Not Moisture Sensitive
REACH Status: REACH Unaffected
Lead Free: Yes

TSW-120-24-G-D Estimated Pricing

Qty Low High
1+ $4.16 $4.16
25+ $4.01 $4.01
50+ $3.82 $3.82
100+ $3.55 $3.55
500+ $3.29 $3.29
1,000+ $2.90 $2.90
2,500+ $2.55 $2.55
5,000+ $2.18 $2.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSW-120-24-G-D Features

  • 40 position 2-row through hole header.
  • 0.100 inch (2.54mm) pitch spacing.
  • Gold plated phosphor bronze contacts.
  • Unshrouded push-pull mating design.
  • UL94 V-0 rated PBT insulator.

TSW-120-24-G-D Applications

  • Board-to-board vertical stacking connections.
  • Cable-to-board connection with IDC sockets.
  • Prototyping and test fixture assemblies.
  • General purpose signal interconnects.

TSW-120-24-G-D FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does this header have?

40 positions arranged in 2 rows (2x20).

What is the pitch of the TSW-120-24-G-D?

The pitch is 2.54mm (0.100 inches).

What is the mounting style of this header?

Through hole solder termination.

What is the contact finish on this part?

Gold, 0.25µm thick.

Is the header shrouded or unshrouded?

Unshrouded.

What is the operating temperature range?

-55°C to 125°C.
