Mfr Part #:

TSW-117-14-L-D

34 Position, 2.54mm pitch, through hole, unshrouded header with tin contact finish. Suitable for board-to-board or cable applications.

✓ Total Stock: 622 pcs

$ Price Range: $1.06 - $2.94

TSW-117-14-L-D Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
HMB Electronics LLC ✓ Non-Authorised Inventory information	622 pcs On Request	622 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TSW-117-14-L-D Description

Short technical summary and product information.

The Samtec TSW-117-14-L-D is a 34-position, 2-row, through-hole header with a 2.54mm pitch. It features an unshrouded design with square pins made of phosphor bronze, plated with tin (10µin thickness). The insulator is black PBT with a UL94 V-0 flammability rating.

This header supports board-to-board and cable-to-board interconnects. It has a push-pull fastening mechanism and an operating temperature range of -55°C to 125°C. The overall contact length is 0.530" (13.46mm) with a contact post length of 0.320" (8.13mm).

Packaged in bulk, this component is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited). It is a standard through-hole header suitable for general-purpose interconnect applications in industrial and consumer electronics.

TSW-117-14-L-D Quick Information

Product Type: Header, Male Pins

Series: TSW

Canonical Name: Samtec TSW-117-14-L-D - 34 Position, 2.54mm Pitch, Through Hole, Tin Contact Finish, Unshrouded Header

Subcategory: Unshrouded Header

TSW-117-14-L-D Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): Not Moisture Sensitive

REACH Status: REACH Unaffected

TSW-117-14-L-D Estimated Pricing

Qty	Low	High
1+	$2.94	$2.94
50+	$2.56	$2.56
100+	$2.23	$2.23
500+	$2.04	$2.04
1,000+	$1.67	$1.67
2,000+	$1.49	$1.49
5,000+	$1.27	$1.27
10,000+	$1.06	$1.06

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSW-117-14-L-D Features

34 position, 2 row, 2.54mm pitch header.
Through hole mounting with solder termination.
Unshrouded design for board-to-board or cable.
Tin contact finish with 10µin thickness.
Operating temperature range -55°C to 125°C.

TSW-117-14-L-D Applications

Used in PCB interconnect applications.
Suitable for board-to-board stacking.
Ideal for cable-to-board connections.
Common in industrial and consumer electronics.

TSW-117-14-L-D FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does this header have?

34 positions (2 rows of 17).

What is the pitch of the TSW-117-14-L-D?

2.54mm (0.100").

What is the mounting style?

Through hole with solder termination.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Tin with 10µin (0.25µm) thickness.

What is the insulation material and flammability rating?

PBT (Polybutylene Terephthalate) with UL94 V-0 rating.

What packaging is available?

Bulk.

Category	Headers, Male Pins
Manufacturer Name	Samtec Inc.
Connector Type	Header
Contact Finish	Tin
Contact Finish Thickness	10.0µin (0.25µm)
Contact Length	8.13mm (0.320")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	2.54mm (0.100")
Insulation Material	Polybutylene Terephthalate (PBT)
Lead Spacing	2.54 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	34
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-55°C ~ 125°C
Overall Contact Length	0.530" (13.46mm)
Pitch	2.54mm (0.100")
Row Spacing	0.100" (2.54mm)
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	No
Termination	Solder
