TSW-105-17-G-S Samtec TSW-105-17-G-S is a 0.100" (2.54mm) pitch, 5-position, single-row, unshrouded through-hole header. It features gold-plated phosphor bronze contacts and a black PBT insulator rated UL94 V-0.
Mfr Part #:

TSW-105-17-G-S

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec TSW-105-17-G-S is a 0.100" (2.54mm) pitch, 5-position, single-row, unshrouded through-hole header. It features gold-plated phosphor bronze contacts and a black PBT insulator rated UL94 V-0.
✓ Total Stock: 274 pcs
$ Price Range: $0.36 - $0.89

TSW-105-17-G-S Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
274 pcs
On Request
274 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSW-105-17-G-S Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Shrouding
Style
Tape & Reel
Termination
Voltage Rating
View Similar Products (0)

TSW-105-17-G-S Description

Short technical summary and product information.

The TSW-105-17-G-S is a straight pin header from Samtec's TSW series, offering a classic 0.100" (2.54mm) pitch for board-to-board or cable applications. This single-row, unshrouded header has 5 positions loaded with square pins made of phosphor bronze and plated with 10µin gold over 50µin nickel. The insulator is black PBT with UL94 V-0 flammability rating.



Electrical ratings include 550 VAC when mated with SSW socket strips and 6.3 A per pin when mated with SSQ socket strips with 2 positions powered. It operates over -55°C to +125°C with gold plating. The overall contact length is 0.830" (21.08mm) with a post length of 0.620" (15.75mm).



Typical mating connectors include Samtec SSW, SSQ, SSM, ESW, ESQ, BCS, and other socket strips. The header is designed for through-hole soldering and is suitable for both prototyping and production runs. The TSW series is known for its design flexibility with multiple lead styles and plating options.



Packaging is bulk. Note that the TSW series is not lead-free solderable and should be used with lead wave soldering processes.

TSW-105-17-G-S Quick Information

Product Type: Male Pin Header
Series: TSW
Canonical Name: Samtec TSW-105-17-G-S .100" (2.54mm) Pitch Unshrouded Header, 5 Positions, Single Row, Through Hole, Gold Plating
Subcategory: Unshrouded Header

TSW-105-17-G-S Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Not Moisture Sensitive
REACH Status: REACH Unaffected

TSW-105-17-G-S Estimated Pricing

Qty Low High
1+ $0.89 $0.89
50+ $0.79 $0.79
100+ $0.70 $0.70
500+ $0.61 $0.61
1,000+ $0.53 $0.53
2,000+ $0.46 $0.46
5,000+ $0.41 $0.41
10,000+ $0.36 $0.36

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSW-105-17-G-S Features

  • 5 positions in single row layout.
  • 2.54mm (0.100") pitch spacing.
  • Gold plated phosphor bronze contacts.
  • Through-hole solder termination.
  • UL94 V-0 rated PBT insulator.

TSW-105-17-G-S Applications

  • Board-to-board or cable connections.
  • Suitable for standard 0.100" pitch applications.
  • Ideal for prototyping and production.
  • Mates with Samtec socket strips.
  • Used in industrial control systems.

TSW-105-17-G-S FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the TSW-105-17-G-S header have?

5 positions in a single row.

What is the pitch of TSW-105-17-G-S?

2.54 mm (0.100 inch).

What is the current rating of this header?

6.3 A per pin when mated with SSQ socket strip with 2 positions powered.

What is the voltage rating?

550 VAC when mated with SSW socket strip.

What is the mounting type?

Through hole (solder termination).

What is the operating temperature range?

-55°C to +125°C with gold plating.

What is the contact finish thickness?

10 µin (0.25 µm) gold over 50 µin nickel.
