| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,358 pcs
|
6358 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
300 pcs
|
300 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Size | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Orientation | |
| Overall Contact Length | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec TSW-105-14-T-D is a 10-position, 2-row through hole header with a 2.54mm (0.100 inch) pitch. It features tin plated phosphor bronze square pins (0.025 inch square post) and a black PBT insulator rated UL94 V-0. The unshrouded vertical design supports board-to-board and cable interconnects with push-pull fastening. Operating temperature range is -55°C to 105°C. This header is part of Samtec's TSW series, offering a wide variety of pin counts, terminal lengths, and plating options for design flexibility. Termination is through hole solder, and packaging is bulk.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.66 | $0.66 |
| 50+ | $0.59 | $0.59 |
| 100+ | $0.53 | $0.53 |
| 500+ | $0.43 | $0.43 |
| 1,000+ | $0.33 | $0.33 |
| 2,000+ | $0.28 | $0.28 |
| 5,000+ | $0.24 | $0.24 |
| 10,000+ | $0.21 | $0.21 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions, 2 rows.
2.54mm (0.100 inch).
Through hole.
-55°C to 105°C.
UL94 V-0.
Phosphor bronze with tin plating.
Polybutylene Terephthalate (PBT), black.
