TSW-103-07-S-S CONN HEADER VERT 3POS 2.54MM. This is a 3-position, single row, through hole header with 2.54mm pitch and tin plated contacts.
Mfr Part #:

TSW-103-07-S-S

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
CONN HEADER VERT 3POS 2.54MM. This is a 3-position, single row, through hole header with 2.54mm pitch and tin plated contacts.
✓ Total Stock: 3,580 pcs
$ Price Range: $0.22

TSW-103-07-S-S Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
3,580 pcs
$0.22 ℹ
Qty Price
0+ 0.22
3580 pcs $0.22
QtyPrice
0+ 0.22
1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSW-103-07-S-S Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Orientation
Overall Contact Length
Pitch
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TSW-103-07-S-S Description

Short technical summary and product information.

The TSW-103-07-S-S is a 3-position, single row, through hole header from Samtec's TSW series. It features a 2.54mm (0.100") pitch and unshrouded vertical orientation. The contacts are made of phosphor bronze with a tin finish (30µin thickness). The insulation is black PBT with UL94 V-0 flammability rating. This header is suitable for board-to-board or cable applications. It has a push-pull fastening type and solder termination. The operating temperature range is -55°C to 125°C. Packaging is bulk.

TSW-103-07-S-S Quick Information

Product Type: Header, Male Pins
Series: TSW
Canonical Name: Samtec TSW-103-07-S-S 3-Position 2.54mm Pitch Through Hole Header
Subcategory: Unshrouded Header

TSW-103-07-S-S Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Not Moisture Sensitive
REACH Status: REACH Unaffected

TSW-103-07-S-S Estimated Pricing

Qty Low High
1+ $0.35 $0.35
250+ $0.34 $0.34
500+ $0.32 $0.32
1,000+ $0.21 $0.21
2,500+ $0.20 $0.20

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSW-103-07-S-S Features

  • 3 positions in single row.
  • 2.54mm (0.100") pitch spacing.
  • Through hole solder termination.
  • Tin plated phosphor bronze contacts.
  • Unshrouded vertical header design.

TSW-103-07-S-S Applications

  • Board-to-board connection applications.
  • Cable-to-board interconnect systems.
  • Prototyping and test fixtures.
  • General purpose signal routing.

TSW-103-07-S-S FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the TSW-103-07-S-S have?

3 positions.

What is the pitch of this header?

2.54mm (0.100").

What is the mounting type?

Through hole.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Tin with 30µin thickness.

What is the insulation material?

Polybutylene Terephthalate (PBT) with UL94 V-0 rating.

Is this header shrouded?

No, it is unshrouded.
