TSM-110-01-T-DV-P-TR Samtec TSM-110-01-T-DV-P-TR is a 20-position, 2-row surface mount unshrouded header with 2.54mm pitch. It features tin-plated phosphor bronze contacts and a black LCP insulator.
Mfr Part #:

TSM-110-01-T-DV-P-TR

Available from 2 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec TSM-110-01-T-DV-P-TR is a 20-position, 2-row surface mount unshrouded header with 2.54mm pitch. It features tin-plated phosphor bronze contacts and a black LCP insulator.
✓ Total Stock: 650 pcs
$ Price Range: $0.82 - $2.02

TSM-110-01-T-DV-P-TR Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
OTL Components ✓
Non-Authorised Inventory information
500 pcs
On Request
500 pcs On Request 1 On Request On Request On Request On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
150 pcs
On Request
150 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSM-110-01-T-DV-P-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
SVHC Present
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TSM-110-01-T-DV-P-TR Description

Short technical summary and product information.

The Samtec TSM-110-01-T-DV-P-TR is a 20-position, 2-row unshrouded header from the TSM series. It features a 2.54mm pitch and is designed for surface mount soldering. The contacts are made of phosphor bronze with a tin finish, and the insulator is black Liquid Crystal Polymer (LCP) rated UL94 V-0. The operating temperature range is -55°C to +105°C.



This header is suitable for board-to-board or cable applications. It includes a plastic pick and place pad for automated assembly. The part is supplied in tape and reel packaging, indicated by the -TR suffix. The contacts are square male pins with a length of 5.84mm.



Electrical ratings depend on the mating connector: when mated with SSM series, the current rating is 5.4A per pin; when mated with BCS series, the voltage rating is 495VAC. The part is lead-free solderable as verified by the datasheet.

TSM-110-01-T-DV-P-TR Quick Information

Product Type: Header, Male Pins
Series: TSM
Canonical Name: Samtec TSM-110-01-T-DV-P-TR 20 Position 2.54mm Pitch Surface Mount Header, Male Pins
Subcategory: Unshrouded Header

TSM-110-01-T-DV-P-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

TSM-110-01-T-DV-P-TR Estimated Pricing

Qty Low High
1+ $2.02 $2.02
150+ $1.54 $1.54
450+ $1.37 $1.37
900+ $1.19 $1.19
1,950+ $1.18 $1.18
4,950+ $0.87 $0.87
9,900+ $0.82 $0.82

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSM-110-01-T-DV-P-TR Features

  • 20-position, 2-row unshrouded header.
  • 2.54mm pitch for standard spacing.
  • Surface mount with solder termination.
  • Tin-plated phosphor bronze contacts.
  • Black LCP insulator rated UL94 V-0.

TSM-110-01-T-DV-P-TR Applications

  • Suitable for board-to-board connections.
  • Ideal for cable-to-board applications.
  • Used in industrial and consumer electronics.
  • Pick and place compatible for automated assembly.

TSM-110-01-T-DV-P-TR FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the TSM-110-01-T-DV-P-TR have?

It has 20 positions arranged in 2 rows.

What is the pitch of this header?

The pitch is 2.54mm (0.100").

What is the current rating?

The current rating is 5.4A per pin when mated with SSM series connectors.

What is the voltage rating?

The voltage rating is 495VAC when mated with BCS series connectors.

What is the mounting type?

Surface mount (SMD).

What is the operating temperature range?

-55°C to +105°C.

What is the insulation material and flammability rating?

Black Liquid Crystal Polymer (LCP) with UL94 V-0 rating.
