TSM-108-01-F-DV-P-TR The Samtec TSM-108-01-F-DV-P-TR is a 16-position strip header with a 2.54mm pitch and vertical orientation. It is designed for surface mount applications.
Mfr Part #:

TSM-108-01-F-DV-P-TR

Available from 1 distributors
Mfr Name: SMT
SMT
The Samtec TSM-108-01-F-DV-P-TR is a 16-position strip header with a 2.54mm pitch and vertical orientation. It is designed for surface mount applications.
✓ Total Stock: 150 pcs

TSM-108-01-F-DV-P-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
150 pcs
On Request
150 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSM-108-01-F-DV-P-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mating Cycles
Number of Positions
Number of Rows
Orientation
Pitch
SVHC Present
Tape & Reel
Termination
View Similar Products (0)

TSM-108-01-F-DV-P-TR Description

Short technical summary and product information.

This Samtec TSM-108-01-F-DV-P-TR is a surface mount strip header featuring a 0.100 inch (2.54 mm) pitch and 16 positions across two rows. The vertical orientation and .025 inch square post contact system make it suitable for various interconnect applications. It offers performance up to 8 Gbps and meets or exceeds MIL-DTL-55302 testing standards.



The connector is designed for surface mount termination and comes in Tape & Reel packaging with 150 parts per package. It is also an Extended Life Product, designed for high mating cycles ranging from 250 to 2,500, and passes 10-year Mixed Flowing Gas (MFG) testing. This makes it a robust choice for demanding applications.



Key features include its compact design, high mating cycle capability, and suitability for high-speed data transmission. The SET Qualified Product designation indicates its suitability for severe environment testing.

TSM-108-01-F-DV-P-TR Quick Information

Product Type: Strip Header
Series: TSM
Canonical Name: SMT TSM-108-01-F-DV-P-TR Strip Header
Subcategory: Rectangular Connectors

TSM-108-01-F-DV-P-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TSM-108-01-F-DV-P-TR Features

  • 16 positions, 2 rows, 2.54mm pitch.
  • Vertical orientation, surface mount termination.
  • Supports up to 8 Gbps data rates.
  • High mating cycles: 250 to 2,500.
  • Meets MIL-DTL-55302 testing.

TSM-108-01-F-DV-P-TR Applications

  • Suitable for high-speed board-to-board connections.
  • Ideal for applications requiring high mating cycles.
  • Used in environments requiring severe testing.
  • Surface mount design simplifies assembly.

TSM-108-01-F-DV-P-TR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of the Samtec TSM-108-01-F-DV-P-TR?

The pitch of the TSM-108-01-F-DV-P-TR is 2.54 mm.

How many positions does the TSM-108-01-F-DV-P-TR have?

The TSM-108-01-F-DV-P-TR has 16 positions.

What is the orientation of the TSM-108-01-F-DV-P-TR?

The orientation of the TSM-108-01-F-DV-P-TR is vertical.

What termination type does the TSM-108-01-F-DV-P-TR use?

The TSM-108-01-F-DV-P-TR uses surface mount termination.

What is the performance capability of the TSM-108-01-F-DV-P-TR?

The TSM-108-01-F-DV-P-TR supports up to 8 Gbps performance.

What is the mating cycle rating for this connector?

The TSM-108-01-F-DV-P-TR has a mating cycle rating of 250 to 2,500.

Does the TSM-108-01-F-DV-P-TR meet MIL-DTL-55302 standards?

Yes, the TSM-108-01-F-DV-P-TR meets or exceeds MIL-DTL-55302 testing.
