TSM-106-02-T-SH Samtec TSM-106-02-T-SH is a 6 position single row right angle surface mount header with 2.54mm pitch, tin plated phosphor bronze contacts, and LCP insulation.
Mfr Part #:

TSM-106-02-T-SH

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec TSM-106-02-T-SH is a 6 position single row right angle surface mount header with 2.54mm pitch, tin plated phosphor bronze contacts, and LCP insulation.
✓ Total Stock: 150 pcs
$ Price Range: $0.23 - $0.84

TSM-106-02-T-SH Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
150 pcs
On Request
150 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSM-106-02-T-SH Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Halogen Free
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TSM-106-02-T-SH Description

Short technical summary and product information.

The Samtec TSM-106-02-T-SH is a 6-position single row right angle surface mount header from the TSM series. It features 2.54mm (0.100") pitch, square post contacts of phosphor bronze with tin plating, and a post height of 8.13mm (0.320"). The insulator is black liquid crystal polymer (LCP) with UL94 V-0 flammability rating. This header is designed for surface mount soldering termination and is suitable for board-to-board or cable applications. It is rated for operating temperatures from -55°C to 105°C. The part is RoHS3 compliant, lead-free solderable, and has MSL 1 unlimited moisture sensitivity. As an Extended Life Product, it passes 10-year mixed flowing gas testing and supports up to 250 to 2,500 mating cycles. It is also Severe Environment Testing (SET) qualified, meeting MIL-DTL-55302 testing requirements. The standard packaging is tube with 38 pieces per tube.

TSM-106-02-T-SH Quick Information

Product Type: Header, Male Pins
Series: TSM
Canonical Name: Samtec TSM-106-02-T-SH, 6 Position Single Row Right Angle Surface Mount Header, 2.54mm Pitch, Tin Plating
Subcategory: Unshrouded Header, Male Pins

TSM-106-02-T-SH Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): MSL 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

TSM-106-02-T-SH Estimated Pricing

Qty Low High
1+ $0.84 $0.84
38+ $0.66 $0.66
114+ $0.45 $0.45
532+ $0.41 $0.41
1,026+ $0.39 $0.39
2,014+ $0.34 $0.34
5,016+ $0.30 $0.30
10,032+ $0.23 $0.23

Estimated market price range - modelled values for guidance only, not live distributor offers.

TSM-106-02-T-SH Features

  • 6 position single row right angle SMT header.
  • 2.54mm (0.100") square post pitch.
  • Tin plated phosphor bronze contacts.
  • Operating temperature range -55°C to 105°C.
  • Extended Life Product with 10 year MFG testing.

TSM-106-02-T-SH Applications

  • Ideal for board-to-board interconnect applications.
  • Used in industrial and automotive electronics.
  • Suitable for high-reliability and harsh environment systems.
  • Compatible with various Samtec sockets for flexible configurations.

TSM-106-02-T-SH FAQs

5 frequently asked questions generated from this part’s specifications.
What is the number of positions?

6 positions.

What is the pitch?

2.54mm (0.100").

What is the mounting type?

Surface Mount, Right Angle.

What is the operating temperature range?

-55°C to 105°C.

What is the contact finish?

Tin.
