TSM-105-01-S-DV-P-TR The Samtec TSM-105-01-S-DV-P-TR is a straight surface mount pin header. It features 10 contacts arranged in 2 rows with a 2.54mm pitch.
Mfr Part #:

TSM-105-01-S-DV-P-TR

Available from 1 distributors
Mfr Name: SMT
SMT
The Samtec TSM-105-01-S-DV-P-TR is a straight surface mount pin header. It features 10 contacts arranged in 2 rows with a 2.54mm pitch.
✓ Total Stock: 150 pcs

TSM-105-01-S-DV-P-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
150 pcs
On Request
150 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TSM-105-01-S-DV-P-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector System
Contact Material
Contact Plating
Current Rating
Failure Rate
Lead Style
Mounting Type
Number of Contacts
Number of Rows
Product Type
SVHC Present
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

TSM-105-01-S-DV-P-TR Description

Short technical summary and product information.

This Samtec TSM Series pin header is designed for surface mount applications. It offers a 2.54mm pitch and a straight orientation, with 10 contacts made of phosphor bronze and plated with gold.



The header has a current rating of 4A and a voltage rating of 475V. It operates within a temperature range of -55°C to 125°C. The termination type is solder, and it is suitable for wire-to-board connections.



This product is an Extended Life Product, passing 10 year Mixed Flowing Gas (MFG) and achieving high mating cycles. It is designed specifically for surface mount applications with many options to facilitate processing.

TSM-105-01-S-DV-P-TR Quick Information

Product Type: Pin Header
Series: TSM
Canonical Name: Samtec TSM Series Straight Surface Pin Header
Subcategory: Rectangular Connectors

TSM-105-01-S-DV-P-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TSM-105-01-S-DV-P-TR Features

  • 10 contacts in 2 rows.
  • 2.54mm pitch for versatile connections.
  • Surface mount termination style.
  • Phosphor bronze contacts with gold plating.
  • Rated for 4A current and 475V voltage.

TSM-105-01-S-DV-P-TR Applications

  • Ideal for wire-to-board connections.
  • Suitable for high mating cycle applications.
  • Designed for automated surface mounting.
  • Used in extended life product designs.

TSM-105-01-S-DV-P-TR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of the TSM-105-01-S-DV-P-TR?

The pitch is 2.54 mm.

What is the current rating of this pin header?

The current rating is 4 A.

What is the voltage rating of the TSM-105-01-S-DV-P-TR?

The voltage rating is 475 V.

What is the mounting type for this component?

The mounting type is surface mount.

How many contacts does the TSM-105-01-S-DV-P-TR have?

It has 10 contacts arranged in 2 rows.

What is the operating temperature range?

The operating temperature range is -55 °C to 125 °C.

What is the contact material and plating?

The contacts are phosphor bronze with gold plating.
