| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,089 pcs
|
1089 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Material | |
| Contact Plating | |
| Contact Type | |
| Current Rating | |
| Halogen Free | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature Range | |
| Pitch | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating |
The Samtec TS-120-T-A-1 is a 20 position single row screw machine terminal strip header from the TS series. It features a 2.54mm (0.100 inch) pitch and through hole solder termination. The contacts are machined phosphor bronze pins with gold plating, housed in a polyester insulator.
This header is rated for 1A current and 500V voltage, with an operating temperature range of -55°C to 125°C. It is packaged in tubes with 11 pieces per tube.
The TS-120-T-A-1 is RoHS3 compliant, REACH unaffected, and UL recognized (E111594). It mates with Samtec SS, SL, HSS, and ESS series socket strips.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.54 | $3.54 |
| 55+ | $3.37 | $3.37 |
| 110+ | $3.18 | $3.18 |
| 506+ | $2.82 | $2.82 |
| 1,001+ | $2.52 | $2.52 |
| 2,002+ | $2.24 | $2.24 |
| 5,005+ | $2.12 | $2.12 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
20 positions.
2.54 mm (0.100 inch).
1 A.
500 V.
Through hole.
