This AC/DC desktop adapter from GlobTek, Inc., model TR9KI2500CCP-N(R6B), provides a 60W power output with a 24V voltage and a maximum current of 2.5A. Designed for versatility, it operates with an input voltage range of 90 to 264 VAC and meets Level VI efficiency standards.
The adapter features a compact desktop (Class II) form factor with dimensions of 121.0mm x 52.0mm x 33.0mm. It includes an IEC 320-C8 input connector and a standard barrel plug output connector (2.1mm I.D. x 5.5mm O.D. x 11.0mm). The polarization is positive center.
Suitable for applications including household appliances and ITE (Commercial) equipment, this adapter complies with international standards such as 60335-1 and 60950-1. It is RoHS3 compliant and has an MSL of 1 Unlimited. The input type requires a cord, which is sold separately.
The adapter has an output voltage of 24V and a maximum output current of 2.5A.
This adapter has a power rating of 60W.
The adapter accepts an input voltage range of 90 to 264 VAC.
The adapter meets Level VI efficiency standards.
The operating temperature range is from 0°C to 40°C.
It uses a Barrel Plug connector with dimensions 2.1mm I.D. x 5.5mm O.D. x 11.0mm.
The adapter is RoHS3 Compliant.
