| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200,000 pcs
|
200000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Load Capacitance | |
| Mounting Type | |
| Noise | |
| Operating Temperature | |
| Output Current | |
| PSRR | |
| Quiescent Current | |
| Thermal Resistance |
The Texas Instruments TPS79301 is a low-dropout (LDO) linear voltage regulator designed for applications requiring stable power delivery. It features a maximum output current of 200mA and supports an input voltage range from 2.7V to 5.5V, with output voltages adjustable from 1.22V to 5.4V.
This regulator boasts low noise characteristics with a typical value of 32 µVrms and high power-supply rejection ratio (PSRR) of 44 dB at 100 KHz. It also has a low quiescent current of 0.17 mA (typical) and a very low dropout voltage of 112 mV (typical).
The TPS79301 is available in fixed-voltage versions and includes an enable feature for power management. It is typically housed in a SOT-23 surface-mount package, making it suitable for space-constrained designs. The operating temperature range is -40°C to 125°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.28 | $0.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum output current for the TPS79301 is 0.2 A.
The TPS79301 has an input voltage range from 2.7 V to 5.5 V.
The TPS79301 offers adjustable output voltage from 1.22 V to 5.4 V, and also has fixed output options including 1.8 V, 2.5 V, 2.8 V, 2.85 V, 3 V, 3.3 V, 4.75 V, and 5.4 V.
The TPS79301 has a typical noise level of 32 µVrms.
The TPS79301 has a PSRR of 44 dB at 100 KHz.
The typical quiescent current for the TPS79301 is 0.17 mA.
The typical dropout voltage for the TPS79301 is 112 mV.
The TPS79301 operates in a temperature range of -40°C to 125°C.
