| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
11,000 pcs
|
11000 pcs | On Request | 1 | On Request | On Request | 2018+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Features | |
| Lead Style | |
| Load Capacitance | |
| Noise | |
| Operating Temperature Range | |
| Output Current | |
| Package / Case | |
| Quiescent Current | |
| SVHC Present | |
| Thermal Resistance |
The Texas Instruments TPS77025DBVRG4 is a low-dropout (LDO) linear voltage regulator. It is designed to provide a stable output voltage with low quiescent current, making it suitable for power-sensitive applications.
This regulator features an input voltage range of 2.7V to 10V and supports adjustable or fixed output voltages from 1.2V to 5.5V. The maximum output current is 50mA, with a typical dropout voltage of 48mV at 50mA. It also includes an enable pin for power control.
The TPS77025DBVRG4 is available in a SOT-23-5 package, measuring 8.12 mm² (2.9 mm x 2.8 mm). It operates within a temperature range of -40°C to 125°C. The device offers a typical noise level of 190 µVrms and a PSRR of 27dB at 100 KHz.
This component is ideal for applications requiring a compact and efficient voltage regulation solution. Its features, such as low quiescent current and enable functionality, contribute to power savings in battery-powered devices and other portable electronics.
The maximum output current is 50 mA.
The input voltage range is 2.7 V to 10 V.
The adjustable output range is 1.2 V to 5.5 V, with fixed options at 1.2 V, 1.5 V, 1.8 V, 2.5 V, 2.7 V, 2.8 V, 3 V, 3.3 V, and 5 V.
The operating temperature range is -40 °C to 125 °C.
The TPS77025DBVRG4 is available in a SOT-23-5 package measuring 2.9 mm × 2.8 mm.
The typical quiescent current is 17 nA.
The typical dropout voltage is 48 mV.
