| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
452,000 pcs
|
452000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,100 pcs
|
2100 pcs | On Request | 1 | On Request | On Request | 2019+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accuracy | |
| Halogen Free | |
| Lead Style | |
| Mounting Type | |
| Noise | |
| Operating Temperature Range | |
| Quiescent Current | |
| Tape & Reel | |
| Thermal Resistance |
The Texas Instruments TPS76316DBVRG4 is a linear, low-dropout (LDO) voltage regulator designed for various power management applications. It can supply up to 150 mA of output current with a maximum input voltage of 10 V and a minimum input voltage of 2.7 V.
This regulator offers a typical dropout voltage of 375 mV and features an enable function for power control. It provides a regulated output voltage with an accuracy of 3% and is available in fixed output options ranging from 1.6 V to 5.0 V, as well as an adjustable version with an output range of 1.5 V to 6.5 V. The device exhibits low noise with 140 µVrms and a PSRR of 41 dB at 100 KHz.
Packaged in a compact SOT-23 surface-mount case with an area of 8.12 mm², the TPS76316DBVRG4 operates within a temperature range of -40°C to 125°C. It requires a minimum load capacitance of 4.7 µF for stable operation. The typical quiescent current is 0.085 mA, making it suitable for power-sensitive applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.28 | $0.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum input voltage is 10 V.
The maximum output current is 0.15 A.
The typical dropout voltage is 375 mV.
The operating temperature range is -40°C to 125°C.
It is available in a SOT-23 package.
Yes, it features an enable function.
